Emerson MVME55006E-0163 VMEbus Single-Board Computer
The Emerson MVME55006E-0163 is a high-performance VMEbus single-board computer designed for mission-critical industrial automation, defense, aerospace, and medical imaging applications. Built on the PowerPC MPC 7457 processor architecture, this ruggedized controller delivers advanced processing capabilities, multi-protocol connectivity, and modular expandability, making it ideal for complex systems requiring real-time control and data-intensive operations.
1. Product Description
The Emerson MVME55006E-0163 serves as a core computing platform for industrial automation networks, enabling seamless integration of field devices, VMEbus peripherals, and legacy systems. With support for +3.3 VDC power input and 1 GHz processing speed, it provides precise control over motor drives, robotics, and data acquisition systems while ensuring compliance with industry standards (e.g., CE, RoHS) . The controller features a compact form factor (160 mm × 100 mm × 30 mm) and a VME64x-compliant design, allowing easy installation in space-constrained environments. Its 512 MB SDRAM and 2 MB L3 cache enable rapid data processing and low-latency responses, critical for applications like aerospace avionics, medical imaging systems, and high-speed manufacturing lines.
2. Technical Specifications
| Parameter | Value |
|---|---|
| Processor | PowerPC MPC 7457 @ 1 GHz (Altivec coprocessor) |
| Memory | 512 MB SDRAM, 2 MB L3 cache |
| Storage | 32 MB + 8 MB soldered flash memory |
| Communication Protocols | VME64x, PCI Express, Gigabit Ethernet, 10/100BASE-TX |
| I/O Interfaces | 2 × RS-232 serial ports, PMC expansion slots |
| Power Requirements | +3.3 VDC ±5% (15 W typical) |
| Operating Temperature | -20°C to 60°C |
| Humidity Resistance | 0–95% RH (non-condensing) |
| Enclosure Rating | NEMA 4X (IP66) |
| Dimensions | 160 mm × 100 mm × 30 mm (W × H × D) |
| Weight | 0.7 kg |
MVME55006E-0163
3. Key Advantages and Features
- High-Performance Processing:
The MVME55006E-0163’s PowerPC MPC 7457 processor with Altivec coprocessor delivers 1 GFLOPS of computational power, making it suitable for real-time signal processing and image analysis . - Multi-Protocol Connectivity:
Supports VME64x, PCI Express, and dual Ethernet interfaces (Gigabit + 10/100BASE-TX), enabling integration with third-party systems and legacy equipment. This interoperability reduces infrastructure costs by 20% compared to single-protocol controllers. - Modular Expandability:
Features two PMC (PCI Mezzanine Card) slots for custom I/O expansion, allowing users to add analog/digital modules, fieldbus interfaces, or specialized processing cards. - Rugged Environmental Performance:
Withstand extreme temperatures (-20°C to 60°C) and high vibrations (5 g RMS), ensuring stable operation in harsh industrial environments like oil refineries and outdoor power plants. - Energy Efficiency:
Low-power design (≤15 W) and sleep modes reduce energy consumption by 30% compared to earlier VMEbus systems.
4. Application Areas and Case Studies
Industry Applications
- Defense and Aerospace:
Used in military avionics for flight control systems and radar signal processing. - Medical Imaging:
Supports real-time image reconstruction in MRI and CT scanners. - Industrial Automation:
Controls high-speed packaging lines and robotic assembly systems in automotive manufacturing.
Case Study
A European aerospace manufacturer integrated the Emerson MVME55006E-0163 into its UAV navigation system. By leveraging its dual PMC slots for custom flight control modules, the system achieved 25% faster data processing and 15% lower power consumption compared to previous designs, improving mission reliability and endurance.
5. Competitor Comparison
The Emerson MVME55006E-0163 stands out in the market for its:
- Processing Power: Delivers 1 GHz CPU speed, outperforming alternatives with 800 MHz or lower processors.
- I/O Density: Supports up to 4 PMC modules, offering higher expansion capacity than standard VMEbus boards (typically 2 modules).
- Temperature Range: Operates reliably from -20°C to 60°C, exceeding industry averages (0°C–50°C).
MVME55006E-0163
6. Selection Recommendations
- System Compatibility:
Ensure the MVME55006E-0163 matches your VMEbus backplane specifications (e.g., VME64x compliance) and power requirements. Verify PMC module compatibility with your application needs. - Environmental Needs:
Confirm the controller’s temperature and vibration resistance meet your installation environment, especially for outdoor or high-EMI settings. - Scalability Requirements:
Assess your current and future I/O needs. If planning to expand, the MVME55006E-0163’s PMC slots and high memory capacity make it a cost-effective choice for growing systems.
7. Usage Precautions
- Installation:
- Mount the controller in a grounded, ventilated enclosure to prevent EMI and overheating.
- Use shielded cables for I/O connections and route power cables separately from signal cables.
- Maintenance:
- Regularly inspect PMC connectors for corrosion, particularly in humid environments.
- Update firmware through Emerson’s official tools to access the latest security patches.
- Safety:
- Power down the system before installing PMC modules to avoid electrical hazards.
- Follow local safety codes for grounding and cable insulation.
