KJ2201X1-HA1

Description

Parameter	Value/Description
Product Model	KJ2201X1 – HA1
Manufacturer	EMERSON
Product Category	Simplex SLS Terminal Block
Input Voltage	30 VDC. This voltage rating enables it to be easily integrated into common industrial power supply systems, providing stable power for its operation.
Max Current per Channel	30 mA. It can handle this current level per channel, ensuring safe and efficient signal transfer, which is suitable for a wide range of sensors and actuators with corresponding current requirements.
Weight	0.18 kg. Its lightweight design makes it convenient for installation and handling, reducing the effort required during the setup process in industrial control cabinets.
Operating Temperature Range	– 25 °C to 60 °C. This wide temperature range allows the KJ2201X1 – HA1 to function effectively in diverse industrial environments, from cold storage facilities to high – temperature manufacturing areas.
Communication Protocol	Supports RS – 485 and Modbus. These widely used communication protocols enable seamless communication with other devices in the industrial network, facilitating data exchange and control system integration.
Memory Capacity	1500 bytes. Sufficient memory space for storing user programs and data, which can be managed through its user – friendly interface, allowing for customization according to specific industrial application needs.
Power Consumption	Typically < 1 W. Low power consumption not only helps in reducing energy costs but also makes it more environmentally friendly, which is beneficial for long – term industrial operation.
Terminal Block Type	Simplex SLS. The simplex configuration is suitable for applications where a single – channel, non – redundant setup is sufficient, providing a cost – effective solution for many industrial scenarios.

KJ2201X1-HA1

• Robust Connectivity Design

• Flexible I/O Configuration

• Enhanced Compatibility

• Oil and Gas Industry

• Food and Beverage Manufacturing

A food and beverage manufacturing plant used the KJ2201X1 – HA1 to manage its production line. The module was responsible for connecting sensors that monitored temperature, humidity, and product flow, as well as actuators that controlled conveyor belts and packaging machines. By using the KJ2201X1 – HA1, the plant was able to increase its production speed by 20% without sacrificing product quality. The module’s ability to handle multiple I/O signals and its compatibility with different types of devices allowed for seamless integration of different parts of the production line. The plant’s management also noted that the KJ2201X1 – HA1‘s built – in diagnostic functions made it easier to identify and fix equipment problems, reducing maintenance time by 30%.

KJ2201X1-HA1

• EMERSON KJ2201X1 – BA1 Logic Solver – SLS 1508: When paired with the KJ2201X1 – HA1, the KJ2201X1 – BA1 can enhance the overall control capabilities. The KJ2201X1 – BA1 is responsible for executing safety instrumented function (SIF) logic, while the KJ2201X1 – HA1 provides the necessary terminal block connections. Together, they form a comprehensive safety – related control solution, which is crucial in industries like oil and gas, where safety is of utmost importance.

• Rosemount Sensors: Integrating Rosemount sensors with the KJ2201X1 – HA1 allows for highly accurate data collection. Rosemount sensors are known for their precision in measuring variables such as temperature, pressure, and flow. The KJ2201X1 – HA1 can then transmit this data to the control system for further processing. In a chemical plant, this combination can accurately monitor chemical reactions, ensuring optimal process control and product quality.

• DeltaV Controllers: The KJ2201X1 – HA1 can work in tandem with DeltaV controllers. The DeltaV controllers can utilize the data transmitted through the KJ2201X1 – HA1 to execute complex control strategies. In a power generation plant, this combination can optimize the operation of turbines and generators, improving power generation efficiency and reliability.

• AMS Suite: The KJ2201X1 – HA1 can be integrated with Emerson’s AMS Suite software. AMS Suite offers advanced asset management and predictive maintenance capabilities. The KJ2201X1 – HA1 can transmit real – time data to AMS Suite, enabling proactive monitoring of industrial assets. In a manufacturing plant, this combination can detect early signs of equipment failures, reducing maintenance costs and unplanned downtime.

• ProVu Meters: Combining the KJ2201X1 – HA1 with ProVu meters provides real – time data visualization. ProVu meters can display the data processed and transmitted by the KJ2201X1 – HA1 in an easy – to – understand format. In a production line, operators can quickly view key process parameters on ProVu meters, enabling them to take immediate action if any abnormal situations occur.
