FOXBORO FBM07

Description

Main Parameters	Value/Description
Product Model	FBM07
Manufacturer	FOXBORO
Product Category	Digital Input Module
Input Channels	16 digital input channels, allowing connection to multiple field – level digital sensors
Input Signal Types	Compatible with contact – based signals and DC voltage inputs, suitable for a wide range of industrial sensors
Voltage Range	Can handle typical DC voltage inputs within the range suitable for industrial applications, ensuring compatibility with common sensor output voltages
Isolation	Galvanic isolation between channels and ground, protecting against electrical interference and enhancing system reliability
Communication Interface	Designed to communicate with control processors within the FOXBORO I/A Series DCS or other compatible control systems
Operating Temperature Range	– 20 °C to + 60 °C, suitable for various industrial environments, from cold storage areas to warm manufacturing workshops
Enclosure	Robust enclosure design, protecting the module from dust, moisture, and minor mechanical impacts in industrial settings
Mounting Method	Standard mounting options for easy installation in control cabinets or on industrial panels
Certification	Complies with relevant industrial standards, ensuring quality and safety in operation

FBM07

• Innovation Point 1: High – Density Input Design

• Innovation Point 2: Enhanced Signal Isolation

• Innovation Point 3: Compatibility and Scalability

In a chemical processing plant, the FOXBORO FBM07 was used to monitor the status of numerous valves and pumps. The module was connected to the position sensors of valves and the run – status indicators of pumps. By accurately detecting the digital signals from these devices, it provided real – time information to the control room. This enabled operators to quickly identify any equipment malfunctions. As a result, unplanned maintenance was reduced by 20%, as issues could be addressed proactively. The plant also reported a 10% increase in overall process efficiency due to better – coordinated equipment operation based on the reliable data from the FBM07 module.

FBM07

• FOXBORO FCP280: This control processor pairs perfectly with the FBM07. The FBM07 sends processed digital data to the FCP280, which then executes control algorithms. In a water treatment plant, the FCP280 can use the data from FBM07 – connected sensors to control the water treatment process more effectively.

• FOXBORO I/A Series DCS: The FBM07 is an integral part of the FOXBORO I/A Series DCS. Once integrated, it becomes part of a comprehensive control solution, allowing for centralized monitoring and control of industrial processes across the entire plant. In a large – scale food production facility, this integration enables better management of different production stages.

• FOXBORO FBM09: The FBM09 is an input/output module that can work in tandem with the FBM07. While the FBM07 focuses on digital input, the FBM09 can handle additional input/output functions. In a packaging plant, they can collaborate to control the packaging machinery, with the FBM07 providing sensor data and the FBM09 controlling actuators.

• FOXBORO FCM10E: This fieldbus communication module enhances the communication capabilities of the FBM07. It enables high – speed data transfer over fieldbus networks, ensuring quick and stable communication between the FBM07 and other components in the control system. In a large – scale industrial complex, this is crucial for real – time data exchange.

• FOXBORO P0916WE: The P0916WE termination cable assembly ensures reliable physical connections for the FBM07 and other devices. It provides stable power and signal transfer, minimizing signal loss and interference, which is vital for maintaining the high – performance operation of the FBM07.
