Product Overview
The General Electric 8115 – DO – DC is a high – performance digital output module, designed to meet the diverse needs of industrial control and automation systems. As part of GE’s advanced product lineup, this module is engineered to deliver reliable and precise digital output capabilities.
The 8115 – DO – DC is widely used in industrial control, building automation, transportation, energy, and electricity sectors. It plays a crucial role in converting digital signals from PLCs or other control devices into controllable switch signals for external device control. This module features 8 isolated output channels, each capable of handling a maximum output current of 2A, ensuring sufficient power to drive a variety of industrial loads. It supports two output modes, NPN and PNP, providing flexibility for different application requirements. Additionally, the output delay can be configured through software, allowing for fine – tuning of the control process. With its overcurrent and short – circuit protection functions, the 8115 – DO – DC ensures safe and stable operation, protecting both the module and the connected equipment.
Technical Specifications
| Parameter Name | Parameter Value |
|---|---|
| Product Model | 8115 – DO – DC |
| Manufacturer | General Electric |
| Product Type | Digital Output Module |
| Number of Channels | 8 |
| Output Type | NPN/PNP |
| Output Current | 2A per channel |
| Output Voltage | 2 – 60 VDC |
| Delay Range | 0 – 100 ms |
| Protection Function | Overcurrent, short – circuit |
| Installation Method | Guide rail installation |
| External Dimensions | 176 mm x 110 mm x 32 mm |
| Weight | 0.3 kg |
| Working Temperature | – 20 ~ 70 ℃ |
| Working Humidity | 5 % – 95 % RH |
8115-DO-DC
Main Features and Advantages
High – Current Output Capability
With each of the 8 isolated channels capable of delivering up to 2A of output current, the 8115 – DO – DC can power a wide range of industrial devices. This high – current capacity makes it suitable for applications where substantial power is required to drive motors, solenoids, or other high – load equipment.
Versatile Output Modes
The support for both NPN and PNP output modes gives users the flexibility to interface with different types of control systems and sensors. This adaptability allows for seamless integration into various industrial setups, whether they are based on NPN – or PNP – type logic.
Configurable Output Delay
The ability to configure the output delay through software is a significant advantage. It enables precise control over the timing of the output signals, which is crucial in applications where the sequence and timing of operations matter, such as in complex manufacturing processes or automated machinery.
Robust Protection Features
The built – in overcurrent and short – circuit protection functions safeguard the module from potential damage due to electrical faults. This not only ensures the reliable operation of the 8115 – DO – DC but also protects the connected devices and the overall industrial system from electrical hazards.
Easy Installation
Designed for guide rail installation, the 8115 – DO – DC can be quickly and easily mounted in control panels. Its compact size of 176 mm x 110 mm x 32 mm and lightweight of 0.3 kg further facilitate installation, reducing the time and effort required for system setup.
8115-DO-DC
Application Field
In industrial control settings, the 8115 – DO – DC is used to control the operation of conveyor belts, robotic arms, and other automated machinery. For example, in a manufacturing plant, it can be used to turn on and off motors that drive conveyor belts, ensuring the smooth movement of products along the production line.
In building automation, the module is deployed to control lighting systems, HVAC units, and access control devices. It can be programmed to turn on lights at specific times or adjust the temperature settings of HVAC systems based on predefined schedules or sensor inputs.
In the transportation industry, the 8115 – DO – DC can be found in applications such as controlling the opening and closing of automated gates in parking lots or the operation of signaling systems in railway yards.
In the energy and electricity sector, it plays a role in controlling the operation of power distribution equipment, such as circuit breakers and relays. It can also be used to monitor and control the performance of generators and other electrical equipment, ensuring the stable supply of electricity.
Related Products
- GE 8115 – DI – DC: This is a digital input module, in contrast to the 8115 – DO – DC which is for output. While the 8115 – DO – DC sends out control signals, the 8115 – DI – DC receives digital input signals from sensors and switches, enabling the control system to monitor the status of various components in the industrial setup.
- GE PAC8000 AI Module: Part of the same PAC8000 series, this analog input module is used to convert analog signals (such as voltage, current, or temperature) into digital values that can be processed by the control system. It complements the 8115 – DO – DC in comprehensive industrial control setups where both analog and digital signals need to be managed.
- GE 8100 Series Controllers: These controllers are designed to work in tandem with modules like the 8115 – DO – DC. They provide the overall control logic, receiving data from input modules and sending commands to output modules such as the 8115 – DO – DC to execute control actions in industrial processes.
- GE 8115 – DO – AC: Similar to the 8115 – DO – DC, but it is designed for alternating current (AC) output applications. It can be used in scenarios where AC – powered devices need to be controlled, expanding the range of applications for GE’s digital output solutions.
- GE Field Terminals for PAC8000: These terminals are used to connect the 8115 – DO – DC to the field wiring. They snap onto the carrier of the PAC8000 system, providing a convenient and reliable connection point for the module to interface with external devices in the industrial environment.
