Product Overview
The GE DS200DCFBG2BNC is a high – precision and reliable output module, playing a significant role in industrial control systems. As part of GE’s extensive product lineup, this module is specifically designed to meet the demanding requirements of various industrial applications. It is an integral part of the control infrastructure, ensuring accurate and stable output signals for smooth operation of industrial processes.
This module is a key component within the GE Speedtronic control system’s Mark VI series. It serves as a single – ended servo I/O terminal board, providing essential connections and control functions. With its ability to handle servo outputs, I/O for LVDT position sensors, and active pulse rate inputs for flow monitoring, the DS200DCFBG2BNC is a versatile solution for industrial control scenarios. It helps in precisely regulating and controlling industrial equipment, contributing to enhanced productivity and reduced downtime in manufacturing, power generation, and other industrial sectors.
Technical Specifications
|
Parameter Name
|
Parameter Value
|
|
Product Model
|
DS200DCFBG2BNC
|
|
Manufacturer
|
GE
|
|
Product Type
|
Output Module
|
|
Output Signal Type
|
Analog Output (12 – bit resolution)
|
|
Servo Output Quantity
|
2
|
|
LVDT Position Sensor I/O Quantity
|
6
|
|
Active Pulse Rate Input Quantity
|
2
|
|
Servo Coil Current Range
|
10 – 120 mA (selectable via jumpers)
|
|
Communication Interface
|
Connects to VSVO processor board using a 37 – pin cable
|
|
Mounting Method
|
Installed on DIN rail with plastic bracket
|
|
Terminal Block Type
|
High – density Euro – Block type (42 or 36 terminals depending on version)
|
|
Operating Temperature Range
|
Industrial – standard temperature range suitable for harsh environments
|
DS200DCFBG2BNC MRP433745
Main Features and Advantages
High – Resolution Analog Output
The DS200DCFBG2BNC offers 12 – bit analog output resolution, ensuring highly accurate signal transmission. This precision is crucial for applications that require fine – tuned control, such as in high – tech manufacturing processes where even the slightest deviation can affect product quality.
Versatile I/O Capabilities
With two servo outputs, six I/O channels for LVDT position sensors, and two active pulse rate inputs, the module can interface with a wide range of industrial sensors and actuators. This versatility makes it suitable for complex control systems, allowing for comprehensive monitoring and control of industrial equipment.
Adjustable Servo Coil Current
The ability to select servo coil current within the 10 – 120 mA range via jumpers provides flexibility in adapting to different servo valve requirements. This feature enables users to optimize the performance of the connected servo systems according to specific application needs.
Space – Saving Design
Designed for DIN – rail mounting, the module can be vertically stacked, saving valuable cabinet space. This is particularly beneficial in installations where space is limited, such as in compact industrial control panels or in retrofitting existing systems.
DS200DCFBG2BNC MRP433745
Application Field
In the power generation industry, the GE DS200DCFBG2BNC is used to control and monitor turbines and generators. Its precise analog output helps in regulating the speed and power output of these critical components, ensuring stable electricity generation. The module’s I/O capabilities are utilized to interface with various sensors that monitor parameters like temperature, pressure, and vibration, enabling timely maintenance and preventing equipment failures.
Within manufacturing plants, especially those involved in precision manufacturing, the DS200DCFBG2BNC plays a vital role. It controls the movement of robotic arms and automated machinery, ensuring accurate positioning and smooth operation. The high – resolution analog output ensures that the manufacturing processes are carried out with the utmost precision, reducing errors and improving product quality.
In the oil and gas sector, this module is used in control systems for pumps, compressors, and valves. It helps in regulating the flow of fluids and gases, ensuring safe and efficient operations. The module’s ability to withstand harsh environmental conditions, such as high temperatures and humidity, makes it a reliable choice for use in oil refineries, gas pipelines, and offshore platforms.
Related Products
- GE DS200DCFBG1BNC: Similar in function to the DS200DCFBG2BNC, but may have different levels of performance or feature sets. It could be an earlier version with potentially less advanced capabilities in terms of output resolution or I/O options.
- GE VSVO processor board: This board is designed to work in tandem with the DS200DCFBG2BNC. The 37 – pin cable connection between them enables seamless data transfer and control, with the VSVO board providing processing power to manage the signals received and sent by the DS200DCFBG2BNC.
- GE other Mark VI series modules: Modules within the same Mark VI series, like those for input functions or different types of output modules, can be integrated with the DS200DCFBG2BNC to build a more comprehensive control system. They complement each other to handle a wider range of industrial control tasks.
- GE DIN – rail accessories: These accessories, such as additional mounting brackets or cable management components, are essential for installing the DS200DCFBG2BNC on DIN rails. They ensure proper and secure installation, enhancing the overall reliability of the module in the control system.
- GE compatible servo valves: These servo valves are designed to work optimally with the DS200DCFBG2BNC‘s servo output capabilities. The compatibility ensures efficient and precise control of the valves, which is crucial in many industrial applications.
Installation and Maintenance
Pre – installation preparation
Before installing the DS200DCFBG2BNC, ensure that the DIN rail where it will be mounted is clean and free from any debris. Check the power supply to confirm it meets the module’s voltage and current requirements. Inspect the 37 – pin cable that will connect the module to the VSVO processor board for any signs of damage. When handling the module, use appropriate electrostatic discharge (ESD) protection to prevent damage to its sensitive components. Plan the layout on the DIN rail, considering space for future expansion or maintenance access.
Maintenance recommendations
Regularly check the status indicators on the DS200DCFBG2BNC to monitor its operation. If any abnormal lights are displayed, refer to the product manual for troubleshooting. Periodically clean the module to remove dust, as dust accumulation can affect its performance, especially in high – temperature environments. Check the connections of the cables and terminals for any signs of looseness or corrosion. Update the module’s firmware when new versions are available from GE to benefit from improved functionality and bug fixes. Conduct routine tests of the servo outputs and sensor inputs to ensure they are working accurately.
Product Guarantee
GE offers a robust product guarantee for the DS200DCFBG2BNC output module. The module is built with high – quality materials and undergoes rigorous quality control processes during manufacturing. GE provides a standard warranty period, during which any manufacturing defects will be addressed promptly. Their team of experienced technical support staff is available to assist customers with any product – related queries or issues. Whether it’s a problem with installation, operation, or maintenance, GE’s support team can offer remote or on – site assistance as required. This guarantee not only reflects GE’s confidence in the quality of the DS200DCFBG2BNC but also their commitment to ensuring customer satisfaction and the long – term reliability of the industrial control systems in which the module is used.
