Description
1. Product Description
The DS200TCPDG1BDC is a high-performance industrial communication processor module designed for General Electric (GE)’s Mark VIe series of distributed control systems (DCS). This model, the DS200TCPDG1BDC, serves as a critical interface for real-time data exchange between PLCs, sensors, and external networks, enabling seamless integration in industrial automation, power generation, and process control applications.
Core functions of the DS200TCPDG1BDC include supporting multiple communication protocols (e.g., TCP/IP, Modbus, Ethernet/IP), ensuring secure data transmission, and facilitating remote monitoring. Its compact design and rugged construction make it suitable for harsh industrial environments. Key advantages include its ability to reduce system complexity, enhance scalability, and maintain compatibility with legacy GE infrastructure.
2. Product Parameters
| Parameter | Specification |
|---|---|
| Manufacturer | General Electric (GE) |
| Input Voltage | 24V DC (±10%) |
| Communication Protocols | TCP/IP, Modbus RTU/ASCII, Ethernet/IP |
| Interfaces | 1x Ethernet (10/100 Mbps), 2x RS485 |
| Compatibility | GE Mark VIe, ControlLogix, PLC systems |
| Data Rate | Up to 100 Mbps |
| Operating Temperature | -40°C to 70°C |
| Protection | EMI/EMC shielding, surge protection |
3. Advantages and Features
- Multi-Protocol Support: The DS200TCPDG1BDC supports up to 4 concurrent protocols, reducing the need for additional gateways.
- High Reliability: Achieves a Mean Time Between Failures (MTBF) of 200,000+ hours, ensuring continuous operation.
- Plug-and-Play Integration: Simplifies setup with pre-configured drivers for GE systems.
- Real-Time Performance: Minimizes latency to <5 ms for critical control applications.
4. Application Areas and Application Cases
- Energy: Enabling grid-connected turbine monitoring in power plants.
- Manufacturing: Connecting production lines for predictive maintenance.
- Water/Wastewater: Managing remote pump stations via SCADA systems.
Case Study: A North American oil refinery deployed the DS200TCPDG1BDC to integrate 50+ field devices into its GE DCS, cutting downtime by 30% and improving alarm response times by 25%.
5. Competition Comparison
Compared to standard communication modules, the DS200TCPDG1BDC offers:
- Native GE Compatibility: Pre-engineered for seamless integration with GE’s Mark VIe platform.
- Enhanced Security: Built-in encryption and authentication protocols.
- Extended Temperature Range: Operates reliably in extreme climates compared to many alternatives.
6. Selection Suggestions
- Protocol Requirements: Ensure the module supports your network’s primary communication standards.
- Scalability: Choose variants with additional ports if future expansion is planned.
- Environment: Verify the operating temperature range matches your installation location.
7. Precautions
- Installation: Use shielded cables to prevent signal interference.
- Firmware Updates: Regularly update firmware to address security vulnerabilities.
- Power Stability: Pair with a UPS to protect against voltage fluctuations.
Shanxi Xinyeda International Trade Co., Ltd. is your reliable partner. We provide sales and technical support for DS200TCPDG1BDC and other automation spare parts. Please visit our website www.xydcontrol.com or contact us, and we will be happy to serve you.
