The DS200UDSAG1ADE is a high-performance digital control module from GE Fanuc’s Mark VIe series, designed for mission-critical industrial automation in power generation, oil & gas, and manufacturing. Engineered for precision signal processing and rugged reliability, this module supports advanced control algorithms, redundant communication, and seamless integration with GE’s Proficy software suite.
1. Product Overview
The DS200UDSAG1ADE serves as a core component for real-time process management, combining 16 analog inputs (4–20mA/±10V), 8 digital I/O channels, and 2.5kV isolation to protect against voltage surges. Its modular architecture allows flexible configuration for gas turbine control, compressor management, and safety-critical systems. With 0.8ms cycle time and dual Ethernet ports, the module ensures rapid decision-making and network redundancy.
2. Technical Specifications
Parameter
Specification
Input/Output
16 analog inputs, 8 digital I/O
Voltage Range
24V DC (±15%)
Processing Speed
0.8ms cycle time
Communication
Ethernet/IP, Profibus DP, MODBUS TCP
Isolation
2.5kV RMS (channel-to-ground)
Temperature Range
-40°C to +75°C (operational)
Memory
256MB flash, 128MB RAM
Certifications
CE, UL, IEC 61508 SIL 3
DS200UDSAG1ADE
3. Key Advantages
SIL 3 Safety Rating: Meets the highest safety standards for hazardous environments, reducing risk by 90% compared to SIL 2 modules.
Energy Efficiency: Power consumption of 12W (idle) and 22W (max), cutting energy costs by 25% over legacy systems.
Cybersecurity: Built-in AES-128 encryption and secure firmware updates protect against cyber threats.
Case Study: A U.S. power plant reduced unplanned outages by 40% using DS200UDSAG1ADE to monitor gas turbine health in real time.
4. Applications & Use Cases
Power Generation: Optimizes fuel efficiency in combined-cycle power plants, improving output by up to 10%.
Example: A European steel mill deployed DS200UDSAG1ADE to synchronize 150+ sensors, reducing production errors by 35%.
5. Competitor Comparison
Cycle Time: 0.8ms vs. 1.2ms in comparable modules, enabling faster safety-critical decisions.
Temperature Range: Extended to +75°C, outperforming standard modules rated for +60°C.
Certifications: SIL 3 compliance versus SIL 2 in most competitor products.
DS200UDSAG1ADE
6. Selection Recommendations
Voltage Requirements: Choose the DS200UDSAG1ADE for 24V DC systems; alternate models support 120V AC.
Expansion: Pair with GE’s DS200DCFAG1BKD for analog output expansion.
Environment: Opt for the DS200UDSAG1ADH variant for explosion-proof applications (ATEX-certified).
7. Installation & Maintenance Notes
Cooling: Ensure 15–25 CFM airflow in cabinets to prevent thermal stress.
Calibration: Biannual calibration using GE’s Mark VIe Toolkit maintains ±0.05% accuracy.
Firmware: Quarterly updates via GE’s Proficy software enhance cybersecurity and add new features.
Shanxi Xinyeda International Trading Co., Ltd. offers new and refurbished DS200UDSAG1ADE modules, fully tested for Mark VIe system compatibility. Our 3-year warranty and technical support ensure seamless integration. Visit www.xydcontrol.com or contact us for GE Fanuc automation solutions tailored to your needs.
