F650NFLF2G5HIP6E High-Power IGBT Module for Industrial Automation
The F650NFLF2G5HIP6E is a high-performance insulated-gate bipolar transistor (IGBT) module designed for industrial motor drives, renewable energy systems, and power conversion applications. Manufactured by Fuji Electric, a leading global provider of power electronics solutions, this module combines advanced thermal management, high-current capacity, and rugged construction to deliver reliable operation in demanding environments.
1. Product Overview
The F650NFLF2G5HIP6E serves as a critical component in power conversion systems, enabling efficient energy transfer between AC and DC sources. Its 650V blocking voltage and 500A continuous current rating make it ideal for applications such as variable-frequency drives (VFDs), solar inverters, and electric vehicle (EV) chargers. The module’s direct-bonded copper (DBC) substrate ensures optimal heat dissipation, while -40°C to +125°C operating temperature range guarantees stability in extreme conditions.
2. Technical Specifications
Parameter
Specification
Voltage Rating
650V (maximum)
Current Rating
500A (continuous), 1,500A (pulsed)
Package Type
EconoDUAL 3-phase bridge
Switching Frequency
Up to 20 kHz
Thermal Resistance
0.15°C/W (case to heat sink)
Gate Charge
1,200 nC (typical)
Operating Temperature
-40°C to +125°C (junction)
Mounting
Press-fit or screw-mounted
F650NFLF2G5HIP6E
3. Key Advantages
High Power Density: Delivers 20% higher current capacity than comparable 650V IGBT modules, reducing system size and cost.
Low Power Loss: 1.8V typical saturation voltage minimizes energy waste, improving efficiency by 5% in motor drives.
Rugged Design: IP67-rated enclosure protects against dust and moisture, extending MTBF to 200,000 hours in harsh environments.
Case Study: A German solar farm achieved 98.5% inverter efficiency using F650NFLF2G5HIP6E modules, increasing energy yield by 3% compared to legacy systems.
4. Applications & Use Cases
Industrial Drives: Controls 50–100 HP motors in pumps and compressors, reducing energy consumption by 15%.
Renewable Energy: Powers grid-tie inverters for solar and wind installations, supporting 250 kW peak power.
Transportation: Enables fast-charging EV stations, delivering 500A DC output with minimal heat generation.
Example: A U.S. wastewater plant deployed F650NFLF2G5HIP6E in blower VFDs, cutting annual energy costs by $12,000.
5. Competitor Comparison
Higher Temperature Tolerance: Operates 15°C hotter than standard modules (+125°C vs. +110°C), suitable for compact designs.
Cost Efficiency: 10% lower cost per ampere than equivalent modules, offering superior ROI for large-scale projects.
F650NFLF2G5HIP6E
6. Selection Recommendations
Voltage Matching: Ensure the 650V rating aligns with your system’s DC bus voltage.
Current Requirements: Choose F650NFLF2G5HIP6E for applications exceeding 400A; smaller systems use Fuji’s F300N series.
Environment: Opt for the -HIP6E variant (IP67) for outdoor installations; standard models for indoor use.
7. Installation & Maintenance Notes
Heat Sink Compatibility: Use thermal grease (≤0.1 mm thickness) for optimal heat transfer.
Gate Drive Design: Implement active clamping to prevent overvoltage during switching.
Failure Detection: Monitor collector-emitter voltage for early fault diagnosis.
Shanxi Xinyeda International Trading Co., Ltd. supplies genuine Fuji Electric F650NFLF2G5HIP6E modules with a 3-year warranty, custom configuration services, and global logistics. Visit www.xydcontrol.com for expert technical support and competitive pricing.
