The HE693RTD660 is a precision-engineered RTD (Resistance Temperature Detector) input module designed for GE’s Mark VIe and Mark VIIe gas turbine control systems. Optimized for high-accuracy temperature measurement in critical industrial applications, this module supports multiple RTD types and offers robust signal conditioning for reliable data acquisition.
1. Product Overview
Function: Converts RTD sensor signals into digital data for temperature monitoring and control.
Key Features:
Supports 8 channels of isolated RTD inputs (2-, 3-, or 4-wire configurations).
Compatible with PT100, PT200, PT500, and PT1000 sensors.
Built-in linearization and cold-junction compensation.
Hot-swap capability for maintenance flexibility.
2. Technical Specifications
Parameter
Value
Input Types
RTD (PT100, PT200, PT500, PT1000)
Resolution
16-bit ADC
Accuracy
±0.1°C (at 0–500°C)
Isolation
2.5 kV (input-to-ground)
Power Supply
24 V DC ±10%
Sampling Rate
10 kHz
Operating Temperature
-40°C to +70°C (-40°F to 158°F)
HE693RTD660
3. Key Advantages
High Precision: Factory-calibrated for ±0.1°C accuracy across wide temperature ranges.
Flexible Configuration: Configurable via GE’s Proficy software for custom sensor types.
Rugged Design: Conformal coating protects against dust, moisture, and vibration.
4. Applications
Power Generation: Monitors turbine inlet temperatures and stator winding temperatures.
Oil & Gas: Measures pipeline temperatures in offshore platforms.
Manufacturing: Controls oven and reactor temperatures in chemical processes.
Enhanced Safety: Built-in overvoltage protection and short-circuit detection.
Lower Power Consumption: 50% less power draw compared to similar modules.
HE693RTD660
6. Selection Recommendations
Sensor Compatibility: Verify RTD type (e.g., PT100 vs. PT1000) and wire configuration.
Environmental Conditions: Choose modules with EMI shielding for noisy environments.
Redundancy: Pair with dual RTD sensors for critical temperature measurements.
7. Installation & Maintenance
Wiring: Use twisted-pair cables with proper termination resistors for 3/4-wire RTDs.
Calibration: Perform biannual checks using GE’s calibration tools.
Firmware Updates: Regularly update firmware to ensure compatibility with control system upgrades.
Shanxi Xinyeda International Trading Co., Ltd. supplies refurbished GE HE693RTD660 modules and offers technical support. Visit www.xydcontrol.com for availability or contact us for customized solutions.
