Product Overview
The GE IC660TBD025 is a highly reliable and efficient I/O terminal assembly, proudly crafted by GE Fanuc. It belongs to the esteemed Genius I/O series, which is renowned for its high – performance capabilities in industrial control systems. This terminal assembly is designed to be a key component in various industrial automation setups, facilitating seamless communication and control between different parts of the system.
With its 32 – circuit configuration for discrete input and output, the IC660TBD025 offers remarkable flexibility. It can handle a range of rated voltages, including 5V DC, 12V DC, and 24V DC, making it adaptable to different power requirements within industrial environments. This versatility allows it to be integrated into a wide variety of industrial applications, from manufacturing plants to power generation facilities.
Technical Specifications
|
Parameter Name
|
Parameter Value
|
|
Product Model
|
IC660TBD025
|
|
Manufacturer
|
GE Fanuc
|
|
Product Type
|
I/O Terminal Assembly
|
|
Circuit Configuration
|
32 – circuit discrete input and output
|
|
Rated Voltage
|
5V DC, 12V DC, 24V DC
|
|
Operating Voltage
|
4.9 – 5.3V DC
|
|
Ripple
|
10% max (12V DC and 24V DC), 1% max (5V DC)
|
|
Power Supply Dropout Time
|
4 milliseconds at 12V DC, 20 milliseconds at 24V DC
|
|
Required DC Power
|
150 mA typical, 300 mA maximum
|
|
Heat Dissipation (Max)
|
18 watts
|
|
Maximum Block – to – Block Isolation
|
850 volts
|
|
Dimensions (H x W x D)
|
224 x 90 x 112 millimeters (8.8 x 3.5 x 4.4 inches)
|
|
Weight
|
1.8 kilograms (4 pounds)
|
|
Operating Temperature
|
0 – 60 degrees Celsius (32 – 140 degrees Fahrenheit)
|
|
Storage Temperature
|
– 40 – 100 degrees Celsius (- 40 – 212 degrees Fahrenheit)
|
|
Maximum Output Current per Circuit
|
0.5 amps
|
|
Maximum Inrush Current
|
4 amps for up to 10 milliseconds
|
|
Input Impedance
|
3.3 kΩ
|
|
Input Filter Time
|
1 – 100 milliseconds (selectable)
|
|
Input Processing Time
|
1.4 milliseconds
|
|
Output Turn – on Delay
|
0.5 milliseconds maximum
|
|
Total Block Output Current
|
16 amps
|
IC660TBD025
Main Features and Advantages
High – Voltage Compatibility: The GE IC660TBD025 stands out for its ability to operate with multiple rated voltages. Whether it’s a low – voltage control system or a higher – voltage industrial setup, this terminal assembly can be easily incorporated. This compatibility reduces the need for additional voltage – conversion equipment, simplifying the overall system design and reducing costs.
Reliable Performance: With a maximum block – to – block isolation of 850 volts, it ensures electrical isolation between different parts of the circuit. This isolation protects against electrical interference and short – circuits, enhancing the reliability of the entire industrial control system. Additionally, its wide operating temperature range from 0 to 60 degrees Celsius allows it to function optimally in diverse industrial environments, whether it’s a hot manufacturing plant or a cooler control room.
Flexible Input and Output Configuration: The 32 – circuit discrete input and output design provides great flexibility. It can be configured to handle a large number of input signals from sensors and transmit output signals to various actuators. The selectable input filter time from 1 to 100 milliseconds enables users to adjust the sensitivity of the input based on the specific requirements of the application, further enhancing its adaptability.
Application Field
Manufacturing Industry: In manufacturing plants, the GE IC660TBD025 is used to control and monitor production lines. For example, it can receive input signals from sensors that detect the position of robotic arms, the speed of conveyor belts, or the quality of products being assembled. Based on these inputs, it can send output signals to actuators to control the movement of machinery, ensuring smooth production flow and high – quality output.
Power Generation: In power plants, this terminal assembly plays a crucial role in the control systems. It can interface with sensors that measure parameters such as temperature, pressure, and flow rate in turbines or generators. By processing these input signals, it can send appropriate output signals to control valves, pumps, and other equipment, ensuring efficient power generation and stable operation of the plant.
Industrial Automation Systems: In general industrial automation setups, the IC660TBD025 can be used to integrate different components of the system. It can connect programmable logic controllers (PLCs) with various field devices, enabling seamless communication and control. This helps in automating complex industrial processes, reducing human error, and increasing overall productivity.
IC660TBD025
Related Products
- GE IC660 series: Other modules in the IC660 series may have different input/output configurations or voltage ratings. For example, some may have more or fewer circuits, or be optimized for specific types of industrial applications. The IC660TBD025 is a part of this series, and together they offer a wide range of options for industrial control system design.
- GE Genius I/O modules: These modules are part of the same Genius I/O family as the IC660TBD025. They can be used in combination with the IC660TBD025 to expand the input/output capabilities of the industrial control system. Some may focus on analog inputs or outputs, while the IC660TBD025 is more centered around discrete input and output.
- GE PLCs: Programmable logic controllers from GE can be paired with the IC660TBD025. The PLCs can use the input data received by the IC660TBD025 to execute control programs and send output commands back through the terminal assembly, forming a complete control loop in industrial automation.
- GE Power Supply Modules: These are required to power the IC660TBD025. They need to provide a stable power supply within the specified operating voltage range of the terminal assembly. Different power supply modules may have different power capacities, and the appropriate one can be selected based on the power requirements of the overall system and the IC660TBD025 itself.
- GE Communication Modules: These modules can be used to enable communication between the IC660TBD025 and other devices in a networked industrial control system. They can facilitate data transfer between the terminal assembly and remote monitoring stations, or other control components in a distributed control system setup.
Installation and Maintenance
Pre – installation preparation: Before installing the GE IC660TBD025, ensure that the power supply to the industrial control system is turned off. Check the installation environment to ensure it meets the temperature and humidity requirements specified for the module. Verify that the mechanical mounting space is sufficient, considering its dimensions of 224 x 90 x 112 millimeters. Also, make sure to have the appropriate tools for installation, such as screwdrivers for connecting the Euro – Block type terminal blocks.
Maintenance recommendations: Regularly check the status of the IC660TBD025 by monitoring the input and output signals. Ensure that the voltage levels are within the specified operating range. Clean the module periodically to remove dust and debris, as these can affect its performance over time. Check the connections of the terminal blocks to ensure they are secure. If any issues are detected, refer to the product manual for troubleshooting steps or contact GE’s technical support for assistance.
Product Guarantee
GE Fanuc is committed to providing high – quality products, and the GE IC660TBD025 is no exception. The module is manufactured with strict quality control measures to ensure its reliability and durability. GE offers a comprehensive product guarantee, which includes a standard warranty period. During this time, if there are any defects in materials or workmanship, GE will provide repair or replacement services free of charge. Their team of technical experts is available to offer support for installation, configuration, and any technical issues that may arise during the product’s lifespan. This commitment reflects GE’s confidence in the quality of the IC660TBD025 and their dedication to customer satisfaction in the industrial automation market.
