IC693ALG223

Description

Product Description: GE Fanuc IC693ALG223 Series 90-30 Analog I/O Module

Product Parameters

Parameter	Specification
Channels	4 analog inputs (AI) + 4 analog outputs (AO)
Input Types	Voltage (±10 VDC), current (0–20 mA), thermocouples (J, K, T)
Output Types	Voltage (±10 VDC), current (0–20 mA)
Resolution	12-bit (AI/AO); 14-bit (thermocouple)
Accuracy	±0.1% of full scale (voltage/current); ±2°C (thermocouple)
Isolation	2500 VDC (channels to ground); 500 VDC (AI to AO)
Update Rate	10 ms (AI); 20 ms (AO)
Input Impedance	≥10 MΩ (voltage); 250 Ω (current)
Output Load	≤500 Ω (current); ≥10 kΩ (voltage)
Power Supply	+5 VDC (from baseplate): 120 mA; +24 VDC (external): 50 mA (AO only)
Operating Temperature	0–60°C (32–140°F); storage: -40–85°C
Compatibility	GE Fanuc Series 90-30 baseplates (e.g., IC693CHS392), CPU modules (e.g., IC693CPU363)

IC693ALG223

Advantages and Features

1. Dual-Function Design: 4 AI + 4 AO channels reduce module count and simplify wiring in space-constrained systems.
2. Wide Signal Support: Thermocouple input (J/K/T types) eliminates the need for external signal conditioning.
3. High Reliability: 2500 VDC channel isolation and surge protection (±250 VDC transient) protect against industrial noise.
4. Configurable Filters: Software-selectable low-pass filters (10–1000 Hz) reduce signal noise in analog inputs.
5. Energy Efficiency: Low power consumption (120 mA +5 VDC) minimizes heat generation in compact cabinets.

Application Areas and Use Cases

• Industries: Manufacturing (machine tools), energy (HVAC systems), chemicals (process reactors), and water treatment.
• 典型应用案例:
  A chemical plant used the IC693ALG223 to monitor temperature (K-type thermocouples) and control valve position (4–20 mA outputs) in a reactor. The module’s 14-bit thermocouple resolution reduced temperature measurement errors by 50% compared to legacy modules, while its dual-function design cut wiring costs by 30% in a 20-reactor setup.

Competitor Comparison

• Higher Channel Density: 8 channels (4AI+4AO) vs. 4–6 channels in comparable models.
• Thermocouple Integration: Built-in support (no external modules required) vs. optional add-ons in competitors.
• Isolation Performance: 2500 VDC channel isolation (vs. 1500–2000 VDC in most alternatives).


  IC693ALG223

Selection Recommendations

1. Channel Requirements: Choose the IC693ALG223 for balanced AI/AO needs (4+4); opt for IC693ALG222 (8AI) or IC693ALG224 (8AO) for single-function applications.
2. Signal Types: Verify compatibility with sensors (thermocouples, RTDs, transmitters) and actuators (valves, drives).
3. Environment: Ensure operating temperature (0–60°C) and vibration (IEC 60068-2-6: 10–58 Hz) match site conditions.
4. Software Support: Use LogicMaster 90 (v5.0+) for advanced configuration (e.g., filter settings, scaling).

Precautions

1. Grounding: Connect shielded thermocouple wires to the module’s ground terminal to reduce EMI.
2. Power Stability: Ensure clean +5 VDC (baseplate) and +24 VDC (external) power supplies to avoid output drift.
3. Calibration: Perform periodic calibration (every 2 years) using GE Fanuc’s Proficy software or a precision multimeter.
4. Thermocouple Wiring: Use type-specific extension cables (e.g., K-type for K thermocouples) to maintain accuracy.
5. Output Loading: Do not exceed 500 Ω for current outputs to prevent signal degradation.
