Description

1. Product Description

The IC693BEM341 is a FIP bus controller module belonging to the Series 90-30 programmable logic controller (PAC) family, formerly produced by GE Fanuc Automation and now under Emerson Automation. It is a high-performance module designed for advanced industrial automation systems, providing seamless communication and enhanced control capabilities. This module is equipped with two 9-pin D-shell connectors that support the Factory Instrumentation Protocol (FIP) at a data rate of 2.5 MHz and an RS485 communication port for firmware upgrade. It can interface with the 90-70 series through DIP switch configuration and has four LED status indicators.

2. Product Parameters

  • Communication Ports: Two 9-pin D-shell female FIP connectors and one RS485 port
  • FIP Frequency: 2.5 MHz
  • CPU Requirements: IC693 PLC CPU release 8.10 version or greater
  • Backplane Current Draw: Max 1.2 A, typical 800 mA
  • Operating Temperature: 0°C to +55°C (+32°F to +131°F)
  • Storage Temperature: –25°C to +70°C (–13°F to +158°F)
  • Humidity: 5% to 95% (non-condensing)
  • Operating Vibration: 0.2-inch displacement 5Hz to 10Hz
  • Operating Shock: 1 g 10Hz to 200Hz 5 g 10ms duration

3. Advantages and Features

  • High Communication Speed: With a FIP data rate of 2.5 MHz, it enables fast and efficient data transmission, ensuring smooth operation of the automation system.
  • Versatile Connectivity: The provision of two 9-pin D-shell FIP connectors and an RS485 port allows for easy connection to a variety of devices and systems, enhancing its integration capabilities.
  • Redundancy Management: It can manage the redundancy of slave devices such as I/O nests and drives, improving the reliability and stability of the system. For example, in a manufacturing production line, if one slave device fails, the module can quickly switch to the redundant device to ensure continuous operation.
  • Status Monitoring: The four LED status indicators provide clear information about the module’s operation status, such as carrier detection and transmission enablement, facilitating easy troubleshooting and maintenance.

4. Application Areas and Application Cases

  • Applicable Industries and Scenarios: The IC693BEM341 is suitable for a wide range of industries including manufacturing, energy, and water treatment. In manufacturing, it can be used in production line automation to control and monitor various devices. In the energy industry, it can be applied in power plants for equipment control and data communication.
  • Application Case: In a large-scale automobile manufacturing plant, the IC693BEM341 is used to connect and control multiple robotic arms and conveyor belts on the production line. It ensures the precise coordination of these devices through high-speed FIP communication, improving production efficiency and product quality. The redundancy management function of the module also guarantees the continuous operation of the production line even in the event of device failures.

5. Comparison with Similar Products

Compared to some other FIP bus controllers in the market, the IC693BEM341 stands out with its high data rate of 2.5 MHz, which is higher than some competitors, enabling faster data transmission and more efficient system operation. It also offers comprehensive functions such as redundancy management and status monitoring, which not all similar products have. Moreover, its wide range of compatibility with Series 90-30 and 90-70 systems gives it an edge in integrating with different generations of equipment.

6. Selection Suggestions

  • Compatibility: Ensure that your existing system’s CPU is of IC693 PLC CPU release 8.10 version or greater to ensure compatibility with the IC693BEM341.
  • Installation Environment: Consider the operating temperature and humidity of the installation location. The module is suitable for environments with temperatures ranging from 0°C to +55°C and humidity between 5% and 95% non-condensing.
  • Function Requirements: If your application requires high-speed data communication, redundancy management, and device monitoring functions, the IC693BEM341 is an excellent choice.
  • Budget: Although the IC693BEM341 is a high-performance module, it is necessary to consider your budget. Evaluate the cost-effectiveness based on your actual needs and financial situation.

7. Precautions

  • Installation: When installing the module, make sure to follow the correct installation procedures and connect the cables properly to avoid damage to the connectors and ensure stable communication.
  • Power Supply: Ensure that the power supply meets the requirements of the module to avoid problems such as insufficient power supply affecting the normal operation of the module.
  • Firmware Upgrade: When performing firmware upgrades through the RS485 port, follow the upgrade instructions carefully to prevent incorrect operations that may cause system failures.
  • Environmental Conditions: Do not expose the module to environments outside the specified temperature and humidity range for a long time, as this may affect its performance and service life.
