Product Overview
The GE IS200AEPAH1BKE and GE IS215WEPAH2BB are pivotal components within GE’s industrial automation portfolio, particularly in turbine control systems. The GE IS200AEPAH1BKE is a dual – sided turbine control board. It plays a crucial role in regulating and monitoring the operation of gas or steam turbines. This board’s dual – sided design might offer distinct functionalities on each side, perhaps catering to different turbine functions or being compatible with various GE turbine models. It’s capable of real – time monitoring of critical parameters such as the turbine’s speed, temperature, and vibration. Based on these monitored values, it sends control outputs to adjust turbine components like valves and actuators, ensuring the turbine operates at optimal performance levels.
The GE IS215WEPAH2BB is a printed circuit board from GE’s Mark VI series. It can be utilized in simplex or triple redundancy application types, providing enhanced system reliability. In a fully programmable control system, it supports three software frame rates within the range of 10 to 40 milliseconds. These frame rates determine the time intervals for conditioning and reading inputs, sending outputs, and executing the application software, enabling precise control over the connected systems.
Technical Specifications
For GE IS200AEPAH1BKE
| Parameter Name | Parameter Value |
|---|---|
| Product Model | IS200AEPAH1BKE |
| Manufacturer | GE |
| Product Type | Dual – sided Turbine Control Board |
| Product Origin | USA |
| Weight | 2000g |
| Function | Turbine control, real – time monitoring, control output adjustment |
| Series | Mark VI (inferred from related products) |
| Board Type | Printed Circuit Board (inferred) |
| Relative Humidity | 10 – 95%, non – condensing |
| Shock | Maximum 10 g, non – operating |
For GE IS215WEPAH2BB
| Parameter Name | Parameter Value |
|---|---|
| Product Model | IS215WEPAH2BB |
| Manufacturer | GE |
| Product Type | Printed Circuit Board |
| Series | Mark VI |
| Communication Types | Ionet and UDH |
| Female Plug Connector Quantity | 20 |
| Functional Acronym / Abbreviation | WEPA |
| Humidity | 5 – 95% non – condensing |
| Number of Metal Oxide Varistors | 4 |
| Power Supply Rating | 125 vdc |
| Software Frame Rates | 10, 20 and 40 ms |
| Storage Temperature | – 40 to + 70 °C |
| COM Ports | 3 (COM 1, COM 2, micro – miniature 9 – pin socket D connector) |
| Ethernet Interfaces | 10BaseT/AUI connector |
IS200AEPAH1BKE IS215WEPAH2BB
Main Features and Advantages
For GE IS200AEPAH1BKE
Dual – Sided Design Flexibility
The GE IS200AEPAH1BKE‘s dual – sided structure allows for a more comprehensive approach to turbine control. Each side can be dedicated to specific control functions, such as one side handling speed – related controls while the other manages temperature – based adjustments. This not only simplifies the control architecture but also provides redundancy in case one side malfunctions.
Precise Parameter Monitoring
With its ability to monitor speed, temperature, and vibration in real – time, the board can detect even the slightest deviations from optimal turbine operation. For example, if the turbine’s temperature starts to rise abnormally, the IS200AEPAH1BKE can quickly send signals to adjust the cooling system or fuel – air mixture, preventing potential damage to the turbine.
For GE IS215WEPAH2BB
Redundancy Options
The GE IS215WEPAH2BB‘s compatibility with simplex or triple redundancy application types is a significant advantage. In critical industrial applications where system downtime is unacceptable, such as in power generation plants, the triple – redundancy option ensures that if one board fails, two others can continue to operate, maintaining the integrity of the control system.
Programmable Frame Rates
The support for multiple software frame rates gives users the flexibility to optimize the board’s performance according to the specific requirements of their applications. In high – speed processes where rapid response times are crucial, a shorter frame rate like 10 milliseconds can be selected. Conversely, for applications that require more complex calculations and less immediate response, a longer frame rate such as 40 milliseconds can be utilized.
Application Field
For GE IS200AEPAH1BKE
Power Generation Plants
In gas – fired or steam – powered power generation plants, the GE IS200AEPAH1BKE is used to ensure the efficient operation of turbines. It controls the fuel – air mixture in gas turbines, adjusting the flow rates of fuel and air to achieve optimal combustion. In steam turbines, it manages the steam inlet valves, regulating the amount of steam entering the turbine to control its speed and power output. This helps in maximizing power generation efficiency while minimizing fuel consumption and emissions.
For GE IS215WEPAH2BB
Industrial Manufacturing with Turbine – Driven Machinery
Industries like paper manufacturing, where large – scale machinery is often powered by turbines, rely on the GE IS215WEPAH2BB. The board can be integrated into the control system of these turbines, receiving inputs from sensors that monitor parameters such as the tension in the paper web, the speed of the rollers, and the temperature of the drying cylinders. Based on these inputs, it sends control signals to adjust the turbine’s operation, ensuring consistent product quality and efficient production processes.
Related Products
For GE IS200AEPAH1BKE
- GE IS200AEPAH1AAA: Similar to the IS200AEPAH1BKE, it is a Speedtronic turbine control PCB board. However, it may have different levels of functionality or be designed for a slightly different subset of turbine models within the Mark VI system.
- GE IS200AEPAH1AFD: This printed circuit board, also part of the Mark VI system, can be used in triple modular redundancy and single – 工冗余应用系统. It might have differences in terms of the number of connectors or the specific control algorithms it implements compared to the IS200AEPAH1BKE.
For GE IS215WEPAH2BB
- GE IS215WEPAH2BA: It belongs to the same product series. While sharing some fundamental features with the IS215WEPAH2BB, it could have variations in communication capabilities, power requirements, or the layout of components on the board.
- GE IS210BPPCH1AD: An I/O pack processor board in the Mark VI series. It has a different primary function compared to the IS215WEPAH2BB, focusing on processing and managing I/O signals in the context of I/O packs, but they may work together in a larger Mark VI turbine control system.
Installation and Maintenance
For GE IS200AEPAH1BKE
Pre – installation preparation: Before installing the GE IS200AEPAH1BKE, carefully read the installation manual provided by GE. Ensure that the mounting location is clean, dry, and free from excessive vibrations. Check the power supply to confirm it meets the board’s voltage requirements. Since it has multiple connectors, verify that all connection points in the target system are compatible with the board’s interfaces.
Maintenance recommendations: Regularly inspect the IS200AEPAH1BKE for any signs of physical damage, such as cracks on the board or loose connections. Clean the board periodically to remove dust and debris, as these can affect the performance of the electronic components. Monitor the temperature of the board’s operating environment to ensure it stays within the specified range. If any issues are detected, such as abnormal control signals or incorrect parameter readings, refer to the troubleshooting guide in the user manual or contact GE’s technical support for assistance.
For GE IS215WEPAH2BB
Pre – installation preparation: When installing the GE IS215WEPAH2BB, first, make sure the VME rack where it will be mounted has the appropriate number of slots (13 or 21 – slot racks are typical). Check the integrity of the daughter board connected to the IS215WEPAH2BB and ensure all components are in good condition. Verify that the communication interfaces (Ionet, UDH, Ethernet) are correctly configured and compatible with the rest of the control system.
Maintenance recommendations: Periodically check the status of the female plug connectors on the IS215WEPAH2BB for any signs of wear or corrosion. Monitor the software frame rates to ensure they are operating as expected. If there are any changes in the control system’s performance, such as delays in signal processing, check the board’s power supply rating and the functionality of the metal oxide varistors. Clean the board gently to prevent the accumulation of dust, which could lead to electrical interference.
Product Guarantee
GE stands firmly behind the quality of both the GE IS200AEPAH1BKE and GE IS215WEPAH2BB. These products undergo rigorous testing during the manufacturing process to meet high – quality standards. GE offers a standard warranty period, during which any defects in materials or workmanship will be rectified free of charge. Their experienced technical support team is available to assist customers with installation, configuration, and any technical issues that may arise during the product’s lifespan. Whether it’s a problem with the board’s control functions, communication capabilities, or overall performance, GE is committed to providing timely and effective solutions. This gives customers confidence in their investment and ensures the long – term, reliable operation of these boards in various industrial applications.
