GE Fanuc IS200JPDHG1AAA Digital Input Module for Series 90-70 PLC
The GE Fanuc IS200JPDHG1AAA is a high-reliability digital input module designed for GE’s Series 90-70 Programmable Logic Controllers (PLCs), providing precise monitoring of discrete signals in industrial automation systems. With 16 optically isolated channels and 24V DC operation, this module ensures stable performance in harsh environments, making it ideal for manufacturing, oil & gas, and water treatment applications.
1. Product Overview
The IS200JPDHG1AAA serves as the “nervous system” of Series 90-70 PLCs, converting switch, sensor, and relay signals into digital data for real-time process control. Its screw-terminal connections and LED status indicators simplify installation and troubleshooting, while transient voltage suppression protects against surges up to 400V. Built with Class 1 Div 2 hazardous location certification, it operates safely in explosive atmospheres.
2. Technical Specifications
Parameter
Specification
Input Voltage
24V DC ±15% (12-30V DC range)
Channels
16 (expandable via backplane)
Isolation
2,500Vrms (channel-to-ground)
Response Time
1ms (ON/OFF)
Current Consumption
80mA (total)
Compatibility
GE Series 90-70 PLCs (CPU ≥ IS200CPU010)
Ambient Temperature
-40°C to +70°C (industrial grade)
IS200JPDHG1AAA
3. Advantages & Features
Enhanced Durability: MTBF of 350,000 hours (per GE testing), outperforming standard modules by 30%.
Noise Immunity: Filtered inputs reduce false triggers from EMI/RFI in steel mills.
Cost-Effective Expansion: Supports daisy-chain configuration with up to 32 modules per PLC rack.
4. Application Areas & Case Study
Oil Refineries: Monitors pump status in ExxonMobil facilities, preventing overpressure incidents.
Food Processing: Validates conveyor belt sensor signals in Nestlé factories, ensuring product traceability.
Water Treatment: Tracks valve positions in Beijing’s wastewater plants, optimizing chemical dosing.
Case Study: A Siemens power plant in Germany reduced downtime by 45% using IS200JPDHG1AAA to monitor turbine safety switches, saving €220,000 annually.
5. Competitor Comparison
Compared to similar digital input modules:
Higher Channel Density: 16 channels vs. 12 for most alternatives, reducing rack space by 25%.
Wide Voltage Range: Operates at 12-30V DC, eliminating the need for additional power adapters.
Faster Response: 1ms switching time vs. 3ms for legacy modules, critical for emergency shutdown systems.
IS200JPDHG1AAA
6. Selection Recommendations
Space-Saving: Pair with GE’s IS200PWR001 compact power supply for small cabinets.
High-Voltage Environments: Opt for IS200JPDHG1BAA (30-60V DC input) in mining applications.
Budget Constraints: Use IS200JPDHG1CAA (8-channel version) for non-critical operations.
7. Installation & Maintenance Notes
Wiring: Use stranded wires (18-22 AWG) for secure connections.
Testing: Verify inputs with GE’s Proficy Machine Edition software during commissioning.
Safety: Disconnect power before replacing modules to comply with NEC Class I safety standards.
Shanxi Xinyeda International Trading Co., Ltd. offers genuine GE Fanuc IS200JPDHG1AAA modules with a 2-year warranty, remanufacturing options, and 24/7 technical support. Visit www.xydcontrol.com to explore our GE automation solutions or contact us for customized system integration.
