IS200TDBTH6ABC

Description

Product Specifications

Parameter	Value
Input/Output Signals	16 channels (8 analog, 8 digital)
Signal Types	Analog: 4 – 20 mA, ±10 V; Digital: 24 VDC
Voltage Rating	300 VAC/VDC (continuous), 600 VAC (surge)
Current Capacity	5 A per channel
Isolation	2.5 kV RMS between channels
Temperature Range	-40°C to 85°C (-40°F to 185°F)
Dimensions	228 mm × 102 mm × 76 mm (9.0″ × 4.0″ × 3.0″)
Compatibility	GE Mark VIe system racks, compatible with IS200TDBTH1A and IS200TDBTH2A

IS200TDBTH6ABC

Key Advantages and Features

1. High – Density Connectivity
   • Supports 16 channels in a compact form factor, reducing panel space by 30% compared to legacy solutions.
2. Surge and EMI Protection
   • Built – in transient voltage suppression diodes protect against power surges up to 6 kV.
   • Shielded cabling minimizes electromagnetic interference.
3. Modular Design
   • Quick – disconnect terminals allow hot – swap replacements without system shutdown.
   • Field – replaceable fuses ensure rapid maintenance.
4. Wide Operating Range
   • Maintains signal integrity in extreme temperatures and vibration environments.

Applications and Use Cases

• Energy: Connecting temperature sensors and fuel valves in gas turbines.
• Manufacturing: Controlling servo motors and proximity switches in assembly lines.
• Oil & Gas: Monitoring pressure transducers in offshore platforms.

Competitive Edge

• Cost – Effective: Offers 20% more channels per unit than comparable terminal boards.
• Certifications: Compliant with IEC 61000 – 4 – 5 (surge immunity) and UL 508 (industrial control).
• Redundancy Support: Enables dual – channel configurations for critical applications.


  IS200TDBTH6ABC

Selection Guide

1. Signal Requirements:
   • Choose the IS200TDBTH6ABC for mixed analog/digital signals.
   • Opt for IS200TDBTH1A for fully analog channels (0 – 10 V).
2. Environmental Conditions:
   • For corrosive environments, specify the IS200TDBTH6ABCR variant with conformal coating.
   • Ensure adequate airflow in cabinets to prevent overheating.
3. Budget Considerations:
   • Refurbished units with a 2 – year warranty are available at a 30% discount.
   • Pair with the IS200PCCCH1AAA controller for a complete Mark VIe solution.

Installation and Maintenance Tips

1. Installation:
   • Use ferruled wires (16 – 22 AWG) for secure connections.
   • Torque screws to 0.5 N·m (4.4 lbf·in) to avoid loose contacts.
2. Troubleshooting:
   • Check LED indicators: green = normal, amber = fault.
   • Replace faulty channels individually using GE’s plug – and – play modules.
3. Safety:
   • De – energize the system before servicing.
   • Follow NEC Article 408 for industrial control panel wiring.
