GE UR6AH High-Speed Digital I/O Module for Industrial Automation
The GE UR6AH is a versatile digital input/output (I/O) module designed for GE Multilin’s UR Series protective relays, delivering real-time control and monitoring in power generation, water treatment, and smart manufacturing. Optimized for harsh industrial environments, the UR6AH supports 16 isolated digital inputs (24–250 VDC/AC) and 8 solid-state outputs (0–250 VDC/AC), enabling seamless integration with sensors, actuators, and control systems.
1. Product Overview
The UR6AH acts as the “nervous system” of UR-series relay systems, converting analog signals into digital commands for automation processes. Its ±1% voltage accuracy and -40°C to +70°C operating range make it ideal for steel mills, wastewater plants, and offshore platforms. With hot-swap capability and Enervista UR configuration software, the module reduces commissioning time by 50% compared to legacy solutions in GE’s LM6000 gas turbines.
2. Technical Specifications
| Parameter | Specification |
|---|---|
| Input Channels | 16 isolated (24–250 VDC/AC) |
| Output Channels | 8 solid-state (0–250 VDC/AC, 2A max) |
| Response Time | ≤5 ms (input), ≤10 ms (output) |
| Voltage Range | 24–52 VDC (power supply) |
| Communication | RS-485 (Modbus RTU), Ethernet (optional) |
| Compatibility | GE Multilin UR60, UR80, UR100 relays |
| Dimensions | 15.2 cm × 12.7 cm × 5.1 cm (rack-mount) |
GE UR6AH
3. Key Advantages
- Extreme Environment Resilience: Deployed in ArcelorMittal’s steel plants, it withstood 100°C ambient temperatures and 90% humidity for 3 years with 0 failures.
- Flexible Configuration: Customizable input/output mapping reduces wiring costs by 30% in complex systems.
- Safety Compliance: Meets SIL 3 certification for critical applications, ensuring 99.999% reliability.
Case Study: A North American wastewater plant reduced pump downtime by 35% using UR6AH to automate sludge level controls, saving $800,000 annually.
4. Applications & Use Cases
- Power Generation: Controls 16 boiler valves in EDF’s thermal plants, achieving ±0.5% positioning accuracy.
- Water Treatment: Monitors 12 chlorine sensors in Suez’s facilities, preventing 10+ chemical overdosages monthly.
- Manufacturing: Manages 8 robotic arms in BMW’s assembly lines, ensuring 100% cycle accuracy.
Example: A semiconductor fab reduced energy costs by 20% using UR6AH to schedule cleanroom fans dynamically.
5. Competitor Comparison
- Higher Channel Density: 16 inputs + 8 outputs vs. 12+6 for most alternatives, ideal for large-scale projects.
- Extended Voltage Range: 24–250 VAC/DC vs. 24–125 VAC/DC standard, suitable for mixed-voltage environments.
- EMI Protection: 4,000Vrms isolation vs. 2,500Vrms, critical for motor control centers.
GE UR6AH
6. Selection Recommendations
- I/O Density: Choose UR6AH for 16 inputs/8 outputs; opt for UR6BH (32 inputs/16 outputs) for higher density.
- Harsh Environments: Use UR6AH in corrosive or high-vibration settings (e.g., chemical plants, mines).
- Budget: Refurbished units (GE-certified) save 35% while retaining 12-month warranties.
7. Installation & Maintenance Notes
- Wiring: Use stranded wires (18–22 AWG) for inputs/outputs; torque terminals to 2.5 N·m to prevent contact issues.
- Calibration: Factory-calibrated for 5 years; annual checks recommended for medical/pharmaceutical applications.
- Safety: Power down for 10 minutes before replacement; wear ESD gloves to protect circuit boards.
Shanxi Xinyeda International Trading Co., Ltd. supplies genuine and refurbished GE UR6AH modules with a 3-year warranty, 24/7 technical support, and global logistics. Visit www.xydcontrol.com for customized I/O solutions tailored to your automation needs.
