Honeywell CC-PAIH01

Detailed parameter table

Parameter name	Parameter value
Product model	CC – PAIH01
Manufacturer	Honeywell
Product category	HART – enabled analog input module
Electrical performance	Power supply: 24 VDC; Power capacity: Adequate for stable operation, consuming around 60W
Physical size	Compact design, facilitating installation in space – constrained control cabinets
Interface type	Standardized interfaces, ensuring seamless connection with a wide range of industrial sensors
Communication protocol	Supports HART (Highway Addressable Remote Transducer) protocol for two – way communication with smart field devices
Environmental requirements	Operable within a wide temperature range, from – 20 °C to + 60 °C; Resistant to a certain degree of dust and humidity, suitable for harsh industrial settings
Installation method	DIN – rail mounting, allowing for quick and secure installation
Performance indicators	Features 16 channels; Compatible with input types such as 4 – 20 mA, 1 – 5 V, 0 – 5 V; Offers differential / single – ended input options for flexibility

Product introduction

The Honeywell CC – PAIH01 is a sophisticated HART – enabled analog input module, purpose – built for industrial automation systems. As an integral part of Honeywell’s extensive product portfolio, it plays a crucial role in modern industrial control environments.

This module is designed to receive analog signals from various industrial sensors. These sensors could be monitoring critical parameters like temperature, pressure, or flow rate in industrial processes. Once the analog signals are received, the CC – PAIH01 converts them into digital signals that can be easily processed by Programmable Logic Controllers (PLCs) or Distributed Control Systems (DCS). By performing this conversion, it enables real – time monitoring and precise control of industrial processes, ensuring seamless operations and high – quality output.

Core advantages and technical highlights

HART protocol support

The CC – PAIH01 stands out with its support for the HART protocol. This allows for two – way communication with HART – enabled smart instruments. It not only facilitates the transfer of analog data but also enables the configuration and diagnostics of these instruments. For example, in a large – scale industrial plant, operators can remotely access the status of sensors and make necessary adjustments, reducing the need for on – site inspections and maintenance time.

Multiple input channels

Featuring 16 channels, the module has the capacity to simultaneously connect to multiple sensors. This significantly increases data acquisition efficiency. In a complex industrial process where numerous parameters need to be monitored, such as in a chemical plant with multiple reaction vessels, the CC – PAIH01 can handle all the sensor inputs, providing a comprehensive view of the process in real – time.

Versatile input types

It is compatible with a wide range of analog input types, including 4 – 20 mA, 1 – 5 V, and 0 – 5 V. This versatility makes it suitable for use with various sensors commonly found in industrial settings. Whether it’s a current – outputting pressure sensor or a voltage – based temperature sensor, the CC – PAIH01 can accurately capture the signals, ensuring seamless integration with different types of industrial equipment.

Robust design

Engineered with a robust build, the CC – PAIH01 can withstand harsh industrial environments. It is resistant to temperature fluctuations, dust, and humidity, which are common in manufacturing plants, refineries, and power generation facilities. This durability ensures stable performance over an extended period, minimizing downtime and maintenance costs.

Typical application scenarios

Chemical industry

In chemical manufacturing, precise control of process parameters is crucial for product quality and safety. The CC – PAIH01 can be connected to sensors monitoring temperature, pressure, and chemical composition in reactors and pipelines. For instance, in a polymerization process, accurate temperature control is essential. The module’s ability to precisely convert analog signals from temperature sensors enables the DCS to adjust the cooling or heating systems in real – time, maintaining the optimal reaction conditions.

Power generation

Power plants, whether thermal, hydro, or wind, rely on accurate monitoring of various parameters. The CC – PAIH01 can be used to connect to sensors that measure steam temperature and pressure in thermal plants, water level and flow rate in hydro plants, or wind speed and direction in wind farms. The accurate data it provides helps in optimizing power generation efficiency, ensuring stable power supply, and preventing equipment failures.

Food and beverage industry

In food and beverage production, maintaining consistent quality is key. The module can be connected to sensors that monitor parameters such as liquid levels in tanks, temperature during pasteurization, and pressure in filling machines. By accurately converting these analog signals, it enables the control system to ensure that each product batch meets the required quality standards, reducing product waste and enhancing customer satisfaction.

Related model recommendations

CC – PAIH51

Belongs to the same series as the CC – PAIH01. It also supports the HART protocol but may have different channel configurations or performance specifications. For example, it could have a different number of input channels or higher – precision signal conversion capabilities, which can be considered for applications with more complex data – acquisition requirements.

CC – PAIN01

Another analog input module from Honeywell. While it shares the basic function of converting analog signals, it may lack the HART protocol support of the CC – PAIH01. It can be a more cost – effective alternative for applications where HART – enabled devices are not involved.

CC – PAIM01

Designed specifically for handling low – level analog signals, such as those from thermocouples and RTDs. If the application mainly focuses on temperature measurement using these types of sensors, the CC – PAIM01 may be more suitable than the CC – PAIH01, which is more versatile in handling a broader range of input types.

CC – PAOH01

An analog output module. It is used in combination with the CC – PAIH01 in industrial control systems. The CC – PAIH01 is responsible for gathering input data, and the CC – PAOH01 sends out control signals to actuators, such as valves and motors, based on the processed input data.

CC – PAOX01

Similar to the CC – PAOH01 as an analog output module, but with potentially different output channel configurations or performance characteristics. In applications where specific output requirements, like different current or voltage output ranges, are needed, the CC – PAOX01 could be a better choice when paired with the CC – PAIH01.

Installation, commissioning and maintenance instructions

Installation preparation

Before installing the Honeywell CC – PAIH01, ensure the installation environment meets the module’s requirements. The ambient temperature should be within the specified operating range, and the area should be relatively free of excessive dust and moisture. Gather the necessary installation tools, such as a screwdriver for DIN – rail mounting. Thoroughly inspect the module for any signs of damage during transportation. When making electrical connections, strictly follow the wiring diagrams provided in the product manual. Connect the 24 VDC power supply correctly and ensure proper grounding to protect against electrical malfunctions.

Maintenance suggestions

Regularly check the physical condition of the CC – PAIH01 for any signs of wear, corrosion, or loose connections. Dust accumulation can affect the module’s performance, so clean it periodically using a soft brush or compressed air. Monitor the input signals regularly to ensure they are within the expected range. In case of abnormal signals, refer to the troubleshooting guide in the product manual. If a component needs replacement, use only genuine Honeywell spare parts to maintain the module’s performance and reliability. Also, keep the control cabinet well – ventilated to help with heat dissipation.
