SC-UCMX01 51307198-175

1. Detailed parameter table

Parameter name	Parameter value
Product model	SC – UCMX01 51307198 – 175
Manufacturer	Honeywell
Product category	Controller
Communication protocols supported	Modbus RTU, Modbus TCP, and other standard industrial protocols
Input/Output	Multiple digital and analog I/O interfaces, with an onboard I/O module supporting up to 28 channels
Power supply	24 VDC (input voltage range: 18 – 30 VDC, rated input voltage: 24 VDC ± 25%, maximum ripple voltage: 120 mVpp, maximum rated input current: 1.20 A at 30 VDC for controller + 9 IOMs)
Operating temperature range	-20 °C to +60 °C (-4 °F to +140 °F)
Dimensions	190 mm x 99 mm x 141 mm
Mounting	DIN rail or panel mounting options
Status indicators	LED indicators for power, communication, and diagnostic status
Data transfer rate	High – speed communication for real – time data exchange
Environmental protection	IP20 rating, designed for harsh industrial environments

2. Product introduction

The Honeywell SC – UCMX01 51307198 – 175 is a pivotal non – redundant controller within Honeywell’s industrial control systems. It comes equipped with an onboard mixed I/O module, which significantly enhances its functionality in industrial automation setups.

This controller is specifically engineered for applications where system redundancy is not a prerequisite. It offers an efficient and cost – effective approach to monitoring and control tasks. By integrating seamlessly with various industrial devices, the SC – UCMX01 51307198 – 175 serves as a central hub for data collection and processing. It can connect to sensors, actuators, and other components through its multiple I/O interfaces, enabling smooth operation of the overall automation system. Whether it’s in a manufacturing plant or a process control facility, this controller plays a crucial role in ensuring the proper functioning of the industrial processes.

3. Core advantages and technical highlights

High – speed communication

The Honeywell SC – UCMX01 51307198 – 175 enables rapid data exchange, which is essential for real – time control in industrial automation. With high – speed communication capabilities, it can quickly transfer data between field devices and the control system. For instance, in a fast – paced manufacturing line, it ensures that any changes in sensor readings are immediately relayed to the control system, allowing for prompt adjustments. This high – speed data transfer reduces latency and improves the overall responsiveness of the automation system.

Multi – protocol compatibility

This controller supports a wide range of industrial communication protocols such as Modbus RTU and TCP. This multi – protocol compatibility makes it highly versatile, as it can interface with different types of devices and systems. In an industrial environment where multiple legacy and new – generation devices coexist, the SC – UCMX01 51307198 – 175 can communicate with all of them, ensuring seamless interoperability. It eliminates the need for complex and costly protocol converters, streamlining the integration process.

Robust design for harsh conditions

Built with a rugged construction, the SC – UCMX01 51307198 – 175 can endure harsh industrial environments. With an IP20 rating, it is protected from solid objects, and its design allows it to operate within a wide temperature range of -20 °C to +60 °C. In factories with high levels of dust or in outdoor industrial installations exposed to varying temperatures, this controller continues to function reliably. Its robust design ensures long – term performance and reduces the risk of failures due to environmental factors.

4. Typical application scenarios

In the manufacturing industry, the Honeywell SC – UCMX01 51307198 – 175 is extensively used. For example, in an automotive manufacturing plant, it controls the operation of robotic arms on the assembly line. The high – speed communication and precise control capabilities of the controller enable the robotic arms to perform their tasks with high accuracy, ensuring proper assembly of car parts. The multi – protocol support allows it to communicate with different sensors and actuators involved in the manufacturing process, such as proximity sensors and electric motors.

In the process control industry, like in a chemical plant, the SC – UCMX01 51307198 – 175 monitors and controls various process parameters. It connects to temperature, pressure, and flow sensors to collect real – time data. Based on this data, it can adjust the operation of valves and pumps to maintain optimal process conditions. The controller’s ability to work in harsh environments, such as the corrosive atmosphere of a chemical plant, makes it a reliable choice for such applications.

For building automation systems in large commercial buildings, the SC – UCMX01 51307198 – 175 manages HVAC systems, lighting controls, and access control devices. It can integrate with different components of the building automation network, ensuring efficient operation. For example, it can adjust the lighting levels based on the occupancy detected by sensors, or control the temperature settings of the HVAC system to provide a comfortable environment while optimizing energy consumption.

5. Related model recommendations

Honeywell SC – TCMX01

This model is likely from the same series as the SC – UCMX01 51307198 – 175. It may offer similar control functions but could have differences in specific features, such as a different number of I/O channels or enhanced communication capabilities. It can be considered as an alternative for applications where the I/O requirements or communication needs are different from those suitable for the SC – UCMX01 51307198 – 175.

Honeywell SPS5785

Belonging to Honeywell’s industrial control product line, the SPS5785 is a power supply module. It can be paired with the SC – UCMX01 51307198 – 175 as it provides the necessary power for the controller to operate. A stable power supply from the SPS5785 ensures the reliable functioning of the SC – UCMX01 51307198 – 175 in industrial automation systems.

Honeywell SPS5710

Another power – related product, the SPS5710, like the SPS5785, can be used to power the SC – UCMX01 51307198 – 175. It has different power output characteristics, and depending on the power requirements of the overall system and the SC – UCMX01 51307198 – 175 in particular, it can be selected as a power source option.

Honeywell UCM – X02

This might be an upgraded version of the UCM series. It could have improved performance in terms of communication speed, reliability, or additional features. For applications that demand higher – level functionality compared to what the SC – UCMX01 51307198 – 175 offers, the UCM – X02 can be a suitable replacement or an option for system upgrades.

Honeywell C200 – UCM

Specifically designed for the Experion PKS C200 system, the C200 – UCM has enhanced compatibility with this system. If the SC – UCMX01 51307198 – 175 is being used in an Experion PKS C200 – based setup, the C200 – UCM can be considered for its better integration capabilities and potentially more optimized performance within this specific system environment.

6. Installation, commissioning and maintenance instructions

Installation preparation

Before installing the Honeywell SC – UCMX01 51307198 – 175, ensure the installation environment is clean, dry, and free from excessive dust. The ambient temperature should be within the specified operating range of -20 °C to +60 °C. Use appropriate electrical installation tools, such as screwdrivers and wire strippers. Disconnect all power sources from the system where the controller will be installed to prevent electrical shock. Check the compatibility of the SC – UCMX01 51307198 – 175 with the existing electrical infrastructure, including verifying the power supply requirements. When using DIN rail mounting, make sure the DIN rail is securely installed and has enough space to accommodate the controller. For panel mounting, ensure that the panel has the appropriate cutouts and mounting holes.

Maintenance suggestions

For regular maintenance of the Honeywell SC – UCMX01 51307198 – 175, visually inspect the controller periodically for any signs of physical damage, such as cracks in the casing or loose connections. Check the status indicators regularly to monitor the power, communication, and diagnostic status. If there are any abnormal lights, refer to the product manual for troubleshooting. Clean the controller to remove dust, as dust accumulation can affect heat dissipation and performance. When replacing any components, always use genuine Honeywell parts to maintain the integrity and reliability of the controller. If a malfunction occurs, first check the power supply and all connections. If the problem persists, contact Honeywell’s technical support for further assistance.

7. Service and guarantee commitment

Honeywell offers a comprehensive service and guarantee for the Honeywell SC – UCMX01 51307198 – 175. The product comes with a standard warranty period during which any manufacturing defects will be rectified free of charge. Honeywell’s global network of technical support teams is available around the clock. Whether it’s assistance with installation, commissioning, or troubleshooting, customers can rely on the expertise of these support teams. The company also invests in continuous research and development to improve the performance of the SC – UCMX01 51307198 – 175 and provide software updates if applicable. This commitment showcases Honeywell’s confidence in the quality of the product and its dedication to meeting the long – term needs of its customers in the industrial automation field, ensuring a reliable and long – lasting solution.
