High Precision and Reliability: The CP320260 offers precise control outputs, even in demanding applications. It supports multiple control algorithms, providing flexibility in managing complex processes and achieving optimal performance.
Wide Power Range and Compatibility: The amplifier supports a wide input voltage range and can operate with both single-phase and three-phase power supplies. This flexibility makes it suitable for various industrial power systems.
Advanced Feedback Systems: The CP320260 supports resolver and encoder feedback systems, ensuring precise monitoring of motor shaft position.
Robust Design: The module features IP20 protection against solid objects and is designed to operate within a temperature range of 0°C to 40°C.
Safety Features: The amplifier includes overcurrent protection, drive over-temperature indications, and over- and under-voltage protection. These features ensure safe operation and prevent damage.
Get a Quote
Manufacturer:
Part number: KOLLMORGEN CP320260
Our extensive catalogue, including : KOLLMORGEN CP320260 , is available now for dispatch to the worldwide.
  • Full 12-month warranty
  • Available for dispatch immediately
  • We deliver worldwide

Description

Detailed Parameter Table

Parameter Name Parameter Value
Product Model CP320260
Manufacturer Kollmorgen
Product Category Servo Amplifier
Operating Voltage 220 V
Output Frequency 30 kHz
Continuous Current 20 A
Peak Current 40 A (2 sec)
AC Line Input Voltage 190-230 VAC (3-phase)
DC Bus Voltage 270-320 VDC
PWM Switching Frequency Up to 15 kHz
Feedback System Resolver, Encoder
Certifications CE, UL
Operating Temperature Range 0°C to 40°C
Storage Temperature Range -20°C to 70°C
Humidity Range Up to 90% non-condensing
Dimensions (L×W×H) 120 mm × 80 mm × 40 mm
Weight 1.5 kg
KOLLMORGEN CP320260

KOLLMORGEN CP320260

Product Introduction

The Kollmorgen CP320260 is a high-performance servo amplifier designed for precise control applications in industrial automation. It offers reliable operation with a 220V operating voltage and a precise output frequency of 30 kHz. This module is built to withstand harsh industrial conditions, ensuring consistent performance over time. Its robust design includes premium materials that enhance durability and longevity.

Core Advantages and Technical Highlights

High Precision and Reliability: The CP320260 offers precise control outputs, even in demanding applications. It supports multiple control algorithms, providing flexibility in managing complex processes and achieving optimal performance.
Wide Power Range and Compatibility: The amplifier supports a wide input voltage range and can operate with both single-phase and three-phase power supplies. This flexibility makes it suitable for various industrial power systems.
Advanced Feedback Systems: The CP320260 supports resolver and encoder feedback systems, ensuring precise monitoring of motor shaft position.
Robust Design: The module features IP20 protection against solid objects and is designed to operate within a temperature range of 0°C to 40°C.
Safety Features: The amplifier includes overcurrent protection, drive over-temperature indications, and over- and under-voltage protection. These features ensure safe operation and prevent damage.

KOLLMORGEN CP320260

Typical Application Scenarios

The Kollmorgen CP320260 is widely used in various industrial sectors, including:
  • Machine Tools: For precise motion control in CNC machines.
  • Packaging Machinery: To control the movement of packaging lines.
  • Material Handling Systems: For efficient operation of conveyor systems and automated guided vehicles (AGVs).
  • Robotics: To drive motors in robotic arms and other automation equipment.

Related Model Recommendations

  • CP3032x0: A lower power variant with 3 A continuous current, suitable for applications requiring less torque.
  • CP3062x0: A mid-range power variant with 6 A continuous current, offering a balance between power and efficiency.
  • CP3102x0: A higher power variant with 10 A continuous current, suitable for heavy-duty applications.

Installation, Commissioning, and Maintenance Instructions

Installation Preparation: Ensure the environment meets the specified temperature and humidity requirements. Follow the installation manual carefully to ensure proper grounding and connection. Always disconnect the power source before starting the installation process to avoid electrical shock.
Maintenance Suggestions: Regularly inspect the amplifier for signs of damage or wear. Clean the module periodically to remove dust and debris, which can affect performance and longevity. If any issues are detected, consult the troubleshooting guide or contact a professional for assistance. Replace any damaged components promptly to maintain optimal performance and reliability.

Service and Guarantee Commitment

The Kollmorgen CP320260 is backed by a comprehensive warranty, ensuring customer satisfaction and peace of mind. Kollmorgen offers technical support and service to assist with installation, troubleshooting, and maintenance.
