Motorola 01-W3200F-01C

Product Introduction

The Motorola 01-W3200F-01C is a legacy industrial VMEbus non-volatile memory expansion module designed to boost storage capacity for Motorola’s MVME series control systems. Unlike standalone memory modules, Motorola 01-W3200F-01C is optimized for industrial reliability—combining 16 MB Flash EEPROM (for long-term data retention) and 256 KB SRAM (for fast cache access) to address the memory limitations of legacy SBCs like Motorola MVME-214.

In automation architectures, Motorola 01-W3200F-01C acts as a “critical data reservoir”: it stores application firmware, calibration data, and historical logs that standard SBC memory can’t accommodate. For example, a water treatment plant using Motorola MVME162-043 relies on Motorola 01-W3200F-01C to retain 5 years of flow/pressure logs—ensuring compliance with regulatory requirements without frequent data transfers. Its VMEbus compatibility ensures seamless integration, making Motorola 01-W3200F-01C indispensable for extending the life of legacy control systems.

Core Advantages and Technical Highlights

Long-Term Non-Volatile Data Retention: Motorola 01-W3200F-01C’s 16 MB Flash EEPROM retains data for 20+ years at 25°C—far exceeding the 10-year lifespan of consumer-grade Flash. This is critical for applications like aerospace component testing, where Motorola 01-W3200F-01C stores calibration profiles for test rigs using Motorola MVME-2700-761-I/O. Even during power outages, the module preserves data, avoiding costly reconfiguration that would be required with volatile memory-only systems.

Hardware + Software Write Protection: Motorola 01-W3200F-01C includes a physical write-lock switch and software-controlled write enable—double protection against accidental data erasure. In a manufacturing plant, technicians can activate the hardware lock to prevent overwriting production recipes stored on Motorola 01-W3200F-01C, while the host SBC uses software commands to temporarily unlock the module for scheduled updates. This reduces the risk of human error, a leading cause of downtime in legacy systems.

Seamless MVME Series Compatibility: Motorola 01-W3200F-01C is engineered to work with all MVME series SBCs, requiring no custom drivers. A food processing plant upgrading from Motorola MVME-214 to Motorola MVME162-043 can reuse existing Motorola 01-W3200F-01C modules—avoiding the $10,000+ cost of replacing memory infrastructure. Its 3U form factor also fits standard VME chassis, eliminating the need for hardware modifications.

Typical Application Scenarios

In automotive manufacturing, Motorola 01-W3200F-01C supports a legacy robotic welding system using Motorola MVME-214. It stores 12 welding profiles (each 500 KB) and 6 months of weld quality logs (12 MB total) in its Flash EEPROM. The SRAM caches frequently accessed profiles, reducing weld setup time from 2 minutes to 15 seconds—boosting production of 500+ car frames daily. Motorola 01-W3200F-01C’s write protection prevents accidental profile deletion, ensuring consistent weld quality and compliance with ISO 15614 standards.

For utility substation monitoring, Motorola 01-W3200F-01C is paired with Motorola MVME162-043 to log voltage/current data (100 samples/hour) for 5 years. Its -10°C–60°C operating range withstands outdoor substation temperatures, while 20-year data retention eliminates the need for annual data backups. If the SBC fails, Motorola 01-W3200F-01C preserves historical data, enabling technicians to diagnose issues (e.g., voltage spikes) without losing critical context—reducing troubleshooting time by 40%.

Motorola 01-W3200F-01C

Related Model Recommendations

Motorola 01-W3200F-02C: Higher-capacity variant of Motorola 01-W3200F-01C (32 MB Flash EEPROM). Ideal for users needing more storage (e.g., 10+ years of utility logs).

Motorola MVME-214: Integrated controller compatible with Motorola 01-W3200F-01C. Uses the module’s memory to expand firmware storage for small-scale control systems.

Motorola MVME-RAM200: DRAM mezzanine complementary to Motorola 01-W3200F-01C. Adds volatile memory for real-time data processing, while Motorola 01-W3200F-01C handles long-term storage.

Motorola 01-W3483B: Flash memory module for MVME series. Acts as a direct replacement for Motorola 01-W3200F-01C if 8 MB Flash (vs. 16 MB) is sufficient.

Emerson 01-W3200F-01C-R: Refurbished variant of Motorola 01-W3200F-01C. Tested to original specs—cost-effective replacement for failing units.

Motorola MVME-050: Industrial power supply. Powers Motorola 01-W3200F-01C and ensures stable voltage for memory integrity, preventing data corruption.

Motorola MVME-334B: Serial communication module. Works with Motorola 01-W3200F-01C to transmit stored logs (e.g., utility data) to remote servers via RS-485.

Installation, Commissioning and Maintenance Instructions

Installation preparation: Before installing Motorola 01-W3200F-01C, verify the VMEbus chassis has a 3U slot and the host SBC (e.g., Motorola MVME-214) supports A16/D16 addressing. Confirm the power supply provides +5V DC (±5%) and +12V DC (±10%)—use a multimeter to avoid voltage ripple that causes memory errors. Gather tools: anti-static wristband (protects memory chips), torque screwdriver (0.3 N·m for mounting), and a laptop (for BIST verification). Set the write-lock switch to “Unlock” temporarily for initial configuration.

Maintenance suggestions: For daily upkeep, check Motorola 01-W3200F-01C’s LEDs—steady power and no error lights indicate normal operation. Run BIST monthly via the host SBC to verify memory integrity; replace the module if errors are detected. Clean the module’s vents quarterly with compressed air (20 PSI max) to prevent overheating. If data corruption occurs, restore from backups stored on Motorola 01-W3200F-01C’s redundant sectors. Store spare units in anti-static bags (15°C–25°C, 40%–60% humidity) to preserve Flash retention.

Service and Guarantee Commitment

Motorola 01-W3200F-01C is backed by a 12-month warranty from Emerson for refurbished units, covering defects in Flash/SRAM chips and interface components. If a module fails, Emerson provides free 7-day replacement—critical for applications like utility monitoring where memory downtime risks regulatory non-compliance.

For extended support, customers can purchase a 24-month service contract, including 24/7 remote troubleshooting (via phone/email), access to archived firmware tools, and on-site memory recovery assistance. Emerson maintains a global stock of replacement Flash chips for Motorola 01-W3200F-01C until 2035, ensuring legacy systems remain operational. This commitment underscores Emerson’s dedication to supporting critical infrastructure and avoiding costly full-system upgrades.
