NI NI-9505

Product Introduction

The NI NI-9505 is a high-performance full H-bridge brushed DC servo motor drive module designed for precise motor motion control. It is suitable for applications requiring high precision and reliability, such as robotics, automation lines, and laboratory research. The module integrates an encoder interface and a current sensor, allowing direct connection to various actuators like fractional horsepower brushed DC servo motors, relays, lamps, and solenoids.

Core Advantages and Technical Highlights

High Precision Control:

The NI NI-9505 supports PWM signal processing, enabling precise control of motor current and torque by adjusting the PWM duty cycle.

Robust Industrial Design:

With an IP65 protection rating, the module is designed to withstand harsh industrial conditions, including dust and water ingress.

Low Power Consumption:

The module features a low-power sleep mode, consuming only 0.4 mW, making it suitable for battery-powered or space-limited applications.

Flexible Integration:

The NI NI-9505 includes a 9-pin DSUB female connector for encoder inputs and a screw terminal connector for connecting to a DC brushed servo motor and motor DC power supply.

User-Friendly Configuration:

The module is compatible with the LabVIEW FPGA Module, allowing users to develop custom control algorithms for motor drives and actuators.

NI NI-9505

Typical Application Scenarios

The NI NI-9505 is widely used across various industrial sectors:

Robotics: For precise control of robotic arms and joints.

Automation: For controlling motors in packaging lines and other automated machinery.

Laboratory Research: For precise control of experimental setups and devices.

Medical Devices: For controlling motors in medical equipment requiring high precision.

Related Model Recommendations

NI 9931 Higher Power Motor Screw Terminal Accessory: An accessory that can be used with the NI NI-9505 for higher power applications.

Installation, Commissioning, and Maintenance Instructions

Installation Preparation:

Ensure the installation environment meets the specified temperature and humidity requirements. The module should be installed in a location with adequate ventilation to dissipate heat. Verify that the power supply voltage is within the specified range (6V to 30V DC) to avoid damage to the module.

Maintenance Suggestions:

Regularly inspect the installation to ensure the module is securely mounted and all connections are tight. Monitor the operational status of the module to detect any signs of malfunction early. Conduct functional testing on the module at least once a year to ensure optimal performance.

Service and Guarantee Commitment

National Instruments provides comprehensive support for the NI NI-9505, including a robust warranty that ensures product quality and reliability. The company offers extensive after-sales services such as technical support, repair services, and spare part supply. NI’s global network of service centers ensures prompt assistance and expert guidance, demonstrating the company’s commitment to customer satisfaction and product excellence.
