NI PXIE-8135

Product introduction

The NI PXIE-8135 is a sophisticated embedded controller from National Instruments (NI), meticulously crafted to meet the diverse requirements of modern test, measurement, and automation systems. As an integral part of the PXI Express (PXle) platform, this controller combines powerful processing capabilities with energy – efficient operation, making it a versatile choice for a broad spectrum of applications.

Powered by an Intel Core i7 – 6822EQ Quad – Core Processor that can reach speeds of up to 3.6 GHz, the NI PXIE-8135 delivers robust performance for handling complex computational tasks. With support for up to 32GB of DDR4 memory and a 256GB expandable M.2 SSD, it ensures smooth operation when dealing with data – intensive workloads. The x8 Gen 3 PXI Express interface enables rapid data transfer, facilitating seamless communication between the controller and other PXI Express modules. Whether it’s for real – time monitoring in industrial automation, data – driven research in laboratories, or high – precision testing in electronics manufacturing, the PXIE-8135 offers the reliability and efficiency needed to drive these applications forward. Its compatibility with multiple operating systems provides users with the flexibility to choose the ideal software environment for their specific needs.

Core advantages and technical highlights

Balanced Performance and Power Efficiency: The NI PXIE-8135 stands out with its remarkable balance between processing power and energy consumption. The Intel Core i7 – 6822EQ Quad – Core Processor provides ample computing resources to handle complex algorithms and data processing tasks, such as real – time analytics in industrial quality control systems. At the same time, with a typical power consumption of only 45 W, it significantly reduces energy usage compared to more powerful counterparts. This makes it an excellent choice for applications where power efficiency is crucial, such as battery – powered portable measurement devices or large – scale systems where reducing overall energy costs is a priority.

High – speed Data Handling: Thanks to its x8 Gen 3 PXI Express interface, the PXIE-8135 achieves rapid data transfer rates, enabling seamless integration with high – performance PXI Express modules. In applications like high – speed data acquisition from multiple sensors simultaneously, it can quickly collect and process data without bottlenecks. The Gigabit Ethernet, USB 3.0, and serial ports further enhance its connectivity, allowing for efficient communication with external devices and networks. This high – speed data handling capability ensures that the controller can keep up with the demands of real – time applications, providing accurate and timely results.

Versatile Compatibility and Expandability: The NI PXIE-8135 offers broad compatibility with a wide range of NI and third – party software and hardware. Its support for Windows 10 IoT Enterprise and NI Linux Real – Time operating systems gives users the freedom to select the most suitable platform for their applications. The expandable storage feature, starting with a 256GB M.2 SSD, allows users to increase storage capacity as their data storage needs grow. This expandability, combined with its compatibility, makes the PXIE-8135 a future – proof solution that can adapt to evolving project requirements over time.

Compact and Reliable Design: Built with high – quality components, the PXIE-8135 features a compact form factor, measuring 10.16 cm (W) x 17.78 cm (D) x 3.81 cm (H), making it suitable for installation in space – constrained environments. Its robust construction ensures reliable operation in various settings, from controlled laboratory conditions to harsh industrial environments. The operating temperature range of 0 °C to 55 °C and storage temperature range of – 40 °C to 70 °C further enhance its adaptability. The efficient heat dissipation design, along with stable power management, guarantees consistent performance even under prolonged use.

NI PXIE-8135

Typical application scenarios

In industrial automation, the NI PXIE-8135 plays a crucial role in intelligent manufacturing systems. In a smart factory, it can be used as the central controller for automated production lines. By collecting data from sensors monitoring machine status, production speed, and product quality in real – time, the PXIE-8135 can analyze the data and make adjustments to optimize the production process. Its power – efficient design is particularly beneficial in large – scale industrial plants, where reducing energy consumption across multiple controllers can lead to significant cost savings.

In research laboratories, especially those focused on data – intensive scientific experiments, the PXIE-8135 serves as a reliable data acquisition and processing platform. For example, in a materials science experiment that involves collecting and analyzing large amounts of data from multiple sensors, the controller’s high – speed data handling and processing capabilities ensure accurate and timely results. Its compatibility with different operating systems also allows researchers to use a variety of specialized software tools for data analysis and visualization.

In the electronics industry, the NI PXIE-8135 is employed for high – precision testing of electronic components and devices. It can control test equipment, acquire test data at high speeds, and perform in – depth analysis to detect any faults or defects. The expandable storage feature is valuable for storing large volumes of test data for future reference and quality assurance purposes. Its compact size makes it suitable for integration into test benches with limited space.

Related model recommendations

1. NI PXIE-8861: A more powerful alternative to the PXIE-8135, equipped with an Intel Xeon E3 – 1505L v5 Quad – Core Processor. It offers higher processing power and is suitable for applications that demand intensive computational tasks, such as complex simulations and large – scale data analytics. When projects require more robust computing resources, the PXIE-8861can provide the necessary performance boost.
2. NI PXIe – 8840: A cost – effective option with relatively lower processing power compared to the PXIE-8135. It is ideal for basic data acquisition and simple control tasks in educational institutions or small – scale industries where budget constraints are a concern. While it may not match the performance of the PXIE-8135, it still offers reliable operation for less – demanding applications.
3. NI cRIO – 9068: A CompactRIO controller with a different architecture, designed for rugged and distributed control applications. It can be used in conjunction with the PXIE-8135in scenarios where local control at the edge of the network is required, along with centralized data processing. For example, in a remote environmental monitoring system, the cRIO – 9068 can handle local data collection, while the PXIE-8135 can perform in – depth analysis and manage the overall system.
4. NI PXIE-8880: The top – of – the – line model in NI’s embedded controller range, featuring a high – end Intel Xeon processor and extensive memory capacity. It is designed for the most demanding applications, such as large – scale 3D simulations and real – time processing of massive datasets. When extreme performance is needed, the PXIE-8880is the go – to choice, but it comes at a higher cost and power consumption compared to the PXIE-8135.
5. NI PXIe – 8845: Similar to the PXIE-8135but with enhanced I/O capabilities, offering more communication interfaces and higher – speed data transfer for I/O – intensive applications. In systems that require extensive connectivity to a large number of external devices, such as in a complex sensor network or a multi – device control setup, the PXIe – 8845 can provide the additional I/O resources needed, while the PXIE-8135 may be more suitable for applications with balanced I/O and processing requirements.

Installation, commissioning and maintenance instructions

Installation preparation: Prior to installing the NI PXIE-8135, ensure that the PXI Express chassis is powered off and properly grounded. Verify the compatibility of the chassis with the PXIE-8135 in terms of slot type and power supply capacity. Take appropriate electrostatic – discharge (ESD) precautions, such as wearing an ESD wrist strap, to safeguard the controller during handling. When inserting the PXIE-8135 into the chassis, carefully align it with the PXI Express slot and gently push it in until it clicks into place, ensuring a secure connection. Connect all necessary cables, including power cables, Ethernet cables, USB cables, and serial cables, according to the wiring diagrams provided in the product manual.

Maintenance suggestions: Regularly monitor the status indicators on the PXIE-8135 and the PXI Express chassis to check for any signs of abnormal operation. Clean the ventilation openings of the PXIE-8135 and the chassis regularly to prevent dust accumulation, which can impact the cooling efficiency and potentially lead to overheating. Periodically update the operating system, device drivers, and firmware of the PXIE-8135 to ensure compatibility with the latest software and hardware, as well as to benefit from performance improvements and security patches. In case of any issues, such as system freezes, slow performance, or communication failures, first check the cable connections, power supply, and configuration settings. If the problem persists, refer to the troubleshooting guide in the product manual. When replacing any components, use only genuine NI parts to maintain the reliability and performance of the PXIE-8135.

Service and guarantee commitment

We are fully confident in the quality and reliability of the NI PXIE-8135. The product is backed by a comprehensive warranty that covers any manufacturing defects. During the warranty period, if the PXIE-8135 fails to perform as specified, we will repair or replace it free of charge. Our dedicated technical support team is available around the clock to assist customers with installation, commissioning, and any technical issues that may arise. We offer a wide range of online resources, including detailed user manuals, software drivers, and application notes, to help users make the most of the PXIE-8135. Additionally, we are committed to continuous product improvement and regularly release firmware updates and software enhancements to ensure that the PXIE-8135 remains a leading – edge solution in the embedded controller market, providing our customers with reliable and high – performing solutions for their measurement and automation needs.
