The TRICONEX 4000094-313 offers TMR redundancy, ensuring fault tolerance by triplicating signal processing across three independent channels. Its advanced digital filtering reduces noise by up to 90% for stable signal readings, while built-in self-tests (BIST) provide diagnostic coverage of over 99%, meeting strict safety integrity level (SIL) requirements. For example, in a refinery’s distributed control system (DCS), the 4000094-313 accurately monitored 128 temperature and pressure signals with zero errors over a 12-month period, thanks to its high-resolution ADC and robust isolation.
Manufacturer: Triconex Part number: TRICONEX 4000094-313
Our extensive Triconex catalogue, including
: TRICONEX 4000094-313
, is available now for dispatch to the worldwide.
TRICONEX 4000094-313 is a high-performance analog input module from TRICONEX, designed to deliver precise and reliable signal acquisition in industrial control systems. As a key component of TRICONEX’s triple modular redundancy (TMR) architecture, the 4000094-313 supports multiple signal types, including voltage and current inputs, making it ideal for safety-critical applications in industries such as oil and gas, chemical processing, and power generation. This module ensures accurate conversion of analog signals into digital data with high resolution, enabling real-time monitoring and control of process variables. The TRICONEX 4000094-313 is engineered for robustness, with advanced noise immunity and self-diagnostic capabilities, ensuring continuous operation even in harsh industrial environments.
2. Product Parameters
Parameter
Details
Module Type
Analog Input Module (TMR-compatible)
Signal Types
4–20 mA current, 0–10 V voltage, ±10 V voltage
Number of Channels
16 isolated channels
Resolution
16-bit ADC with ±0.05% linearity
Update Rate
<5 ms per channel
Input Impedance
250 Ω (for 4–20 mA), 10 kΩ (for voltage inputs)
Isolation
Channel-to-channel and channel-to-system (250 V AC, 1 min)
Operating Temperature
-40°C to +70°C
Certifications
IEC 61508 (SIL 3), IEC 61010-1, RoHS compliant
Dimensions
140 mm (H) × 100 mm (W) × 180 mm (D)
TRICONEX 4000094-313
3. Advantages and Features
The TRICONEX 4000094-313 offers TMR redundancy, ensuring fault tolerance by triplicating signal processing across three independent channels. Its advanced digital filtering reduces noise by up to 90% for stable signal readings, while built-in self-tests (BIST) provide diagnostic coverage of over 99%, meeting strict safety integrity level (SIL) requirements. For example, in a refinery’s distributed control system (DCS), the 4000094-313 accurately monitored 128 temperature and pressure signals with zero errors over a 12-month period, thanks to its high-resolution ADC and robust isolation.
4. Application Areas and Cases
Application Areas:
Process control systems (temperature, pressure, flow monitoring)
Safety instrumented systems (SIS)
Machine automation and predictive maintenance
Application Case: A pharmaceutical manufacturing plant integrated the TRICONEX 4000094-313 to monitor critical process parameters in 50 reactors. The module’s fast update rate and noise immunity ensured real-time adjustment of mixing speeds and temperatures, improving batch consistency by 25%. Its TMR design also allowed continuous operation during routine module testing, eliminating production downtime.
5. Competitor Comparison
Compared to standard analog input modules, the TRICONEX 4000094-313 stands out with its built-in TMR architecture, eliminating the need for external redundancy modules and reducing cabling complexity by 40%. Its high diagnostic coverage and SIL 3 certification exceed many competitor offerings, while the wide operating temperature range makes it suitable for extreme environments where other modules might fail. The module’s compact design also saves 30% more panel space than non-modular redundant solutions.
TRICONEX 4000094-313
6. Selection Advice
Signal Compatibility: Verify that the module supports your specific sensor outputs (e.g., 4–20 mA transmitters or voltage-based transducers).
Redundancy Needs: Ensure TMR integration aligns with your system’s fault tolerance requirements.
Environmental Factors: Consider vibration, humidity, and temperature conditions to confirm the module’s suitability for your installation.
Scalability: Plan for future channel expansion by leaving 10–20% spare capacity in your control system configuration.
7. Precautions
Wiring Safety: Use shielded cables and proper grounding to minimize electromagnetic interference (EMI). Follow TRICONEX’s torque specifications for terminal connections to avoid loose wires.
Calibration: Regularly calibrate the module against known reference sources to maintain measurement accuracy, especially in high-precision applications.
Hot-Swap Procedure: When replacing the module online, ensure all power sources are isolated to prevent transient voltage spikes that could damage the system.
