WOODWARD 8402-319/8402-119 Actuator Control Modules

1. Product Description

The WOODWARD 8402-319 and 8402-119 are advanced single- and dual-channel actuator control modules designed for precise positioning in industrial automation systems. These modules are widely used in power generation, oil & gas, and process control applications, ensuring reliable operation under harsh conditions. The 8402-319 supports dual-channel redundancy (200 mA per channel), while the 8402-119 offers a single-channel configuration. Both models feature PWM-based output, LVDT/RVDT feedback compatibility, and real-time diagnostics for optimal performance and safety.

2. Product Parameters

Parameter	8402-319	8402-119
Channels	2	1
Output Current	200 mA (max 245 mA)	200 mA (max 245 mA)
Input Voltage	+5 V DC @ 0.5 A, +24 V DC @ 1 A	+5 V DC @ 0.5 A, +24 V DC @ 1 A
Position Accuracy	0.25% of full scale	0.25% of full scale
Feedback Devices	2 per channel (LVDT/RVDT)	1 per channel (LVDT/RVDT)
Max Load Resistance	10 Ω	10 Ω
Dimensions	10.25 × 9.75 × 1 inches	10.25 × 9.75 × 1 inches
Weight	<2 lbs	<2 lbs
Certifications	CE, UL	CE, UL

3. Advantages and Features

Redundancy Options: The 8402-319 provides dual-channel redundancy for fail-safe operation.
Precision Control: PWM technology ensures smooth actuator response and minimal hysteresis.
Fault Detection: Built-in alarms for excitation, feedback, and driver errors.
Wide Compatibility: Supports multiple feedback types (LVDT/RVDT) and analog inputs.
Rugged Design: Operates in temperatures ranging from -40°C to +85°C.

4. Application Areas and Case Studies

Power Generation: Turbine governor systems for steam/gas turbines.
Oil & Gas: Valve positioning in offshore platforms and refineries.
Water Management: Actuator control in pumps and wastewater treatment.

Case Study:
A European power plant reduced turbine actuator failures by 35% using the 8402-319, improving system availability and energy efficiency.

5. Competitor Comparison

Compared to similar modules:

Higher Redundancy: The 8402-319 offers dual-channel operation for critical systems.
Faster Response: Real-time diagnostics enable instantaneous fault recovery.
Flexible Configuration: Adjustable parameters via Woodward’s configuration software.

6. Selection Recommendations

Channel Needs: Choose 8402-319 for redundant systems or 8402-119 for single-channel applications.
Feedback Type: Ensure compatibility with LVDT/RVDT devices in your system.
Space Constraints: Both modules share the same compact form factor for easy integration.

7. Precautions

Mounting: Install vertically in a well-ventilated enclosure.
Wiring: Use shielded cables for feedback signals to minimize interference.
Firmware Updates: Regularly update via Woodward’s software for bug fixes and new features.
Power Supply: Verify input voltage stability to prevent module damage.
