Woodward 9907-167 505E Digital Turbine Speed Controller
1. Product Overview
The Woodward 9907-167 is a high-performance digital speed controller designed for industrial steam turbines, part of the 505E series. It supports single extraction/steam admission control, making it ideal for applications such as generators, compressors, and pumps. With a 32-bit microprocessor, it delivers precise speed, load, and pressure regulation. The controller features a NEMA 4X-rated enclosure (optional) for durability in harsh environments. While now discontinued, Woodward recommends upgrading to the 505 XT series (e.g., model 8200-1310) for enhanced performance and compatibility.
2. Technical Parameters
| Parameter | Specification |
|---|---|
| Input Voltage | 18–32 VDC |
| Communication | 2 × Modbus RTU/ASCII |
| Display | 2-line 12-character LCD |
| Operating Temperature | -25°C to +65°C (without enclosure) |
| Dimensions | 356 × 279 × 102 mm (14×11×4 inches) |
| Weight | <4.5 kg (10 lbs) |
| Safety Certification | Class I, Division 2 (hazardous locations) |
| Control Modes | Speed, load, pressure, ratio/limiter |
3. Advantages and Features
- Flexible Control: Supports single extraction/steam admission for versatile industrial applications.
- Rugged Design: Optional NEMA 4X enclosure ensures resistance to dust, water, and extreme temperatures.
- Real-Time Monitoring: LCD display and Modbus connectivity enable remote diagnostics and parameter adjustments.
- Safety Enhancements: Zero-speed detection, password protection, and fault diagnostics minimize downtime.
- Compact Footprint: Space-saving design suitable for retrofitting older systems.
4. Application Areas and Case Study
Industries:
- Power generation (coal, gas, combined-cycle plants).
- Oil and gas (refineries, offshore platforms).
- Industrial manufacturing (pumps, fans, compressors).
Case Study:
A European power plant upgraded its aging steam turbine control system with the 9907-167, reducing fuel consumption by 8% and improving load response time by 15%. The controller’s ability to handle dual extraction/steam admission optimized energy efficiency in their combined-cycle operations.
A European power plant upgraded its aging steam turbine control system with the 9907-167, reducing fuel consumption by 8% and improving load response time by 15%. The controller’s ability to handle dual extraction/steam admission optimized energy efficiency in their combined-cycle operations.
5. Competitor Comparison
Compared to similar controllers, the 9907-167 stands out for its seamless integration with existing Woodward systems, advanced safety features, and cost-effective retrofitting capabilities. Its modular design allows for easy expansion, while competitors often require complex hardware modifications.
6. Selection Recommendations
- Compatibility: Ensure compatibility with your turbine’s actuator type (single/multi-stage).
- Environment: Opt for the NEMA 4X enclosure if exposed to outdoor or corrosive conditions.
- Budget: Consider the 505 XT series for long-term reliability, as the 9907-167 is no longer in production.
7. Precautions
- Installation: Follow proper grounding and shielding practices to prevent electromagnetic interference.
- Maintenance: Regularly inspect sensor alignment and update firmware for optimal performance.
- Safety: Always isolate power before servicing and adhere to hazardous area regulations.
