1. Product Description
2. Product Parameters
| Parameter | Details |
|---|---|
| Input Voltage | 24V DC ±10% |
| Output Current | 6A |
| Communication Interface | Ethernet, Profibus DP |
| Processor Speed | 100 MIPS |
| Memory | 128 MB Flash, 64 MB RAM |
| Operating Temperature | -20°C to 60°C |
| Dimensions | 160 x 40 x 100 mm |
| Weight | 0.5 kg |
| Compatibility | Compatible with ABB’s industrial automation platforms and many third-party systems |
3. Advantages and Features
- High Processing Power: With a processor speed of 100 MIPS, LXN1604-6 3BHL000986P7000 can quickly process complex control algorithms and data, ensuring real-time response and precise control. For example, in a high-speed packaging production line, it can accurately control the movement and operation of packaging equipment, improving production efficiency and product quality.
- Rich Communication Interfaces: The availability of Ethernet and Profibus DP interfaces enables easy connection and communication with other devices and systems, facilitating seamless integration and information sharing in the industrial network.
- Wide Temperature Range: It can operate stably in the temperature range of -20°C to 60°C, making it suitable for use in various harsh industrial environments, such as cold storage warehouses and high-temperature workshops.
4. Application Areas and Application Cases
- Application Areas: This module is widely used in manufacturing, energy, water treatment, and building automation industries. It can be used in motor control centers, process control systems, and building HVAC control systems.
- Application Case: In a water treatment plant, LXN1604-6 3BHL000986P7000 is used to control the operation of pumps, valves, and water treatment equipment. It monitors water quality parameters and adjusts the operation of equipment in real time through precise control algorithms, ensuring the stable operation of the water treatment process and the quality of treated water.
5. Comparison with Competitors
6. Selection Suggestions
- Compatibility: Make sure that LXN1604-6 3BHL000986P7000 is compatible with your existing control system in terms of communication protocols, voltage levels, and physical interfaces.
- Function Requirements: According to the specific control tasks and functions required in your project, such as the number of input and output points, processing speed, and communication needs, select the appropriate module.
- Budget: Consider the cost-effectiveness of the product. Although LXN1604-6 3BHL000986P7000 offers high performance and reliability, it is necessary to balance the budget and performance requirements.
7. Precautions
- Installation: During installation, ensure that the module is properly fixed and the wiring is correct to avoid vibration and loose connections.
- Electromagnetic Compatibility: Pay attention to electromagnetic interference and take appropriate shielding and grounding measures to ensure the stable operation of the module.
- Software Update: Regularly check for software updates and upgrade the module’s firmware in a timely manner to improve performance and stability.
IC660ELB912J
High-Speed Gigabit Ethernet Connectivity
The IC660ELB921M provides 1Gbps throughput and dual-port flexibility at approximately 1.5 times the cost of the single-port IC660ELB910, making it ideal for users with high-bandwidth needs. A German automotive assembly plant used 12 IC660ELB921M modules to build a gigabit Ethernet network for its RX3i-based production line control system: each module connected an RX3i rack (equipped with IC695CPU331) to 8 robotic arms and 2 HMI terminals. The 1Gbps throughput supported real-time transmission of robotic motion data (1000 data points per second per robot), and the dual-port design enabled separate networks for control and monitoring—reducing data latency by 70% compared to the IC660ELB910, ensuring precise coordination of the assembly line.
Redundant Ring Network for Uninterrupted Operation
Unlike single-port modules (where a cable break shuts down communication), the IC660ELB921M’s ring topology support ensures network redundancy. A US integrated power plant deployed 18 IC660ELB921M modules in a ring network connecting 18 RX3i racks (controlling turbines, boilers, and generators): when a cable between two modules failed, the network recovered within 250ms, and all control loops continued operating without interruption. This reduced unplanned downtime from 4 hours (with single-port modules) to 0 minutes, avoiding $200,000 in lost power generation revenue per incident.
Multi-Protocol Compatibility for Interoperability
Supporting Modbus TCP, Ethernet/IP, and DNP3.0 protocols, the IC660ELB921M ensures seamless integration with diverse industrial devices. A Chinese smart factory used 8 IC660ELB921M modules to connect its RX3i PLC system with third-party equipment: 4 modules acted as Modbus TCP clients to collect data from Siemens S7-1200 PLCs (controlling conveyors), 2 modules served as Ethernet/IP adapters to communicate with Allen-Bradley VFDs, and 2 modules ran DNP3.0 over IP to send data to the plant’s SCADA system. This compatibility avoided the need for expensive protocol converters (which would have cost $30,000), reducing integration costs by 60%.
Advanced Security and Remote Diagnostics
Equipped with 802.1X authentication and a built-in web server, the IC660ELB921M enhances network security and simplifies maintenance. A Middle Eastern oil refinery deployed 10 IC660ELB921M modules in its hazardous area RX3i systems: 802.1X authentication prevented unauthorized access to the control network, and the web server allowed engineers to remotely configure IP addresses and run ping tests. During a recent maintenance cycle, engineers used the built-in packet capture tool to diagnose a communication issue with a DNP3.0 SCADA link—reducing troubleshooting time by 80% compared to modules without remote diagnostics.
