Product Specification: KONGSBERG RPC420 317114 Remote Panel Controller
The KONGSBERG RPC420 317114 is a rugged, user-friendly remote panel controller designed for industrial automation, marine systems, and process control applications. As part of KONGSBERG’s advanced automation portfolio, the RPC420 317114 combines intuitive operation with robust connectivity to monitor and manage critical processes in demanding environments.
1. Product Description
The KONGSBERG RPC420 317114 serves as a human-machine interface (HMI) for real-time system monitoring, parameter adjustment, and fault diagnostics. Key features include:
- Touchscreen Interface: 7-inch color display for easy navigation and data visualization.
- Multi-Protocol Support: Compatibility with Modbus, Profibus, and Ethernet for seamless integration with PLC/DCS systems.
- Redundant Power Inputs: 24V DC dual power supply ensures continuous operation in mission-critical scenarios.
- IP66/IP67 Rating: Dust and water resistance for harsh industrial and maritime conditions.
- Customizable Layouts: Configurable buttons and graphics for tailored user workflows.
2. Product Parameters
| Parameter | Specification |
|---|---|
| Display | 7-inch TFT LCD (800×480 pixels) |
| Input Voltage | 24V DC ±15% (dual redundant) |
| Current Consumption | 0.5A (nominal) |
| Communication Protocols | Modbus RTU/ASCII, Profibus DP, Ethernet |
| Operating Temperature | -20°C to +60°C |
| Storage Temperature | -40°C to +70°C |
| Dimensions | 215mm × 165mm × 55mm |
| Weight | 1.2kg |
| Certifications | CE, RoHS, marine compliance |
3. Advantages and Features
- High Reliability: Built with industrial-grade components and EMI shielding for stable performance in noisy environments.
- Flexible Integration: Supports up to 32 digital/analog I/O points for direct sensor/actuator connectivity.
- Energy Efficiency: Low power consumption (<12W) with sleep mode for extended operation.
- Case Study: A steel mill reduced downtime by 18% using RPC420 317114 for real-time monitoring of furnace temperature and pressure.
4. Application Areas and Cases
- Marine: Engine room monitoring, ballast control, and navigation system interfaces.
- Energy: Power plant operations, renewable energy management, and grid control.
- Industrial Automation: Process line supervision, robotics, and safety system overrides.
- Case Study: A chemical plant improved operator efficiency by 25% with RPC420 317114’s intuitive interface for batch process adjustments.
5. Competitor Comparison
The RPC420 317114 stands out with:
- Extended Temperature Range: Operates in -20°C to +60°C vs. industry-standard -10°C to +50°C.
- Dual Power Redundancy: Built-in redundancy eliminates single points of failure.
- Larger Display: 7-inch screen compared to most 5–6-inch alternatives.
6. Selection Recommendations
- Environment: Choose IP67-rated enclosures for outdoor or washdown applications.
- Redundancy: Opt for dual-unit configurations for safety-critical systems.
- Cost-Effectiveness: Ideal for mid-complexity applications requiring advanced HMI functionality.
7. Precautions
-
Installation: Ensure proper grounding and cable routing to prevent signal interference.
-
Software Updates: Regularly update firmware to access new features and security patches.
-
Calibration: Perform touchscreen calibration every 6 months for optimal responsiveness.
Shanxi Xinyeda International Trading Co., Ltd. is your trusted partner for [KONGSBERG RPC420 317114] and other automation spare parts. Visit our website www.xydcontrol.com or contact us for sales and technical support.
