The NI PCI-6071E is a robust and feature-rich multifunction data acquisition (DAQ) card from National Instruments (NI), a globally recognized leader in measurement and automation solutions. As a significant part of NI’s PCI-based DAQ product series, the PCI-6071E is meticulously designed to offer high-performance data acquisition and control capabilities, making it an optimal choice for a broad spectrum of applications. This versatile card integrates multiple essential functions, including analog input, analog output, digital I/O, and counter/timer operations, providing users with a comprehensive solution for interfacing with real-world signals and automating complex processes.

Based on the PCI bus standard, the NI PCI-6071E can be seamlessly integrated into desktop computers, serving as a vital link between physical sensors, actuators, and computer-based control and analysis software. In industrial manufacturing, it can monitor and regulate production lines by precisely measuring parameters such as temperature, pressure, and vibration. In scientific research, it enables researchers to collect accurate data from experiments, facilitating in-depth analysis and innovation. With its advanced features and reliable performance, the NI PCI-6071E significantly enhances the efficiency and accuracy of data-driven operations, establishing itself as a trusted component in the field of data acquisition.

Technical Specifications

NI PCI-5421

Main Features and Advantages

High-Speed and Accurate Data Acquisition

The NI PCI-6071E excels in data acquisition with its analog input sampling rate of up to 1.25 MS/s and 12-bit resolution. This combination allows it to rapidly and accurately capture data from various sources, even those with fast-changing signals. In applications like high-speed machinery monitoring, where vibrations and other dynamic parameters need to be measured in real-time, the card ensures no data is lost or misinterpreted. The accurate data acquisition provides users with a detailed and reliable view of the measured phenomena, enabling precise analysis and informed decision-making.

Versatile Functionality

With its integrated analog input, output, digital I/O, and counter/timer functions, the PCI-6071E offers remarkable versatility. The 16 single-ended/8 differential analog input channels can connect to a wide range of sensors, while the 2 analog output channels allow for precise signal generation. The 24 digital I/O lines enable control of digital devices, and the 3 counter/timer channels are useful for tasks requiring accurate timing and counting. This all-in-one functionality makes the card suitable for diverse applications, from simple automation tasks to complex research experiments, reducing the need for multiple specialized cards and simplifying system integration.

Software Compatibility and Ease of Use

The NI PCI-6071E is fully compatible with NI-DAQmx driver software, which provides an intuitive programming interface for popular programming languages such as LabVIEW, C, C++, and Python. This compatibility caters to developers with different programming backgrounds, allowing them to quickly develop customized data acquisition and control applications. The user-friendly software interface simplifies the configuration and operation of the card, reducing development time and effort. Whether you are a seasoned professional or a beginner, the PCI-6071E offers an accessible and efficient way to implement data acquisition solutions.

Reliable and Robust Design

Built to withstand the rigors of industrial and laboratory environments, the NI PCI-6071E features a reliable and robust design. Its operating temperature range of 0 – 55 °C ensures it can function in various settings, from normal office environments to demanding industrial sites. The card’s high-quality construction and components contribute to its long-term reliability, minimizing the risk of failures and ensuring consistent performance over time.

NI PCI-5421

Application Field

The NI PCI-6071E has extensive applications across multiple industries. In the automotive industry, it is used for vehicle testing, such as measuring engine performance parameters, monitoring vehicle dynamics, and testing electronic control units. By accurately capturing data, engineers can optimize vehicle design, improve fuel efficiency, and enhance overall vehicle performance.

In the aerospace sector, the card plays a crucial role in testing aircraft components and systems. It can monitor the structural integrity of parts by measuring strain, vibration, and temperature, ensuring the safety and reliability of aircraft during flight. In research laboratories, the PCI-6071E is employed for a wide range of experiments, from material science research to biological signal analysis. Scientists can use it to collect detailed data, which is essential for advancing knowledge in their respective fields.

In industrial automation, the NI PCI-6071E is integrated into control systems to monitor and regulate production processes. It can adjust machine operations based on real-time data, optimize production efficiency, and maintain product quality. Additionally, it is used in environmental monitoring applications to measure air quality, water quality, and other environmental parameters, providing valuable data for environmental protection and management.

Related Products

• NI PCI-6221: Compared to the PCI-6071E, the NI PCI-6221offers higher analog input and output resolution at 16 bits, providing more precise data conversion. It is more suitable for applications that demand extreme accuracy in data acquisition, such as precision sensor calibration and high-end scientific research.
• NI PCI-6251: This high-end multifunction DAQ card has a higher analog input sampling rate of up to 1.25 MS/s and more analog input channels (32 single-ended / 16 differential) than the PCI-6071E. It is designed for applications requiring high-speed and large-scale data acquisition, like high-frequency signal analysis in telecommunications research.
• NI PCI-6733: Specializing in analog output, the PCI-6733has 32 analog output channels with 16-bit resolution, far exceeding the PCI-6071E‘s 2 analog output channels. It is ideal for applications where precise and multi-channel analog signal generation is crucial, such as in audio processing systems or test equipment calibration.
• NI PCI-6534: The PCI-6534offers a high-density digital I/O solution with 48 TTL-level digital I/O lines, compared to the PCI-6071E‘s 24 digital I/O lines. It is suitable for applications focused on complex digital signal processing and control and can be used in conjunction with the PCI-6071E to expand digital control capabilities.
• NI PCI-6612: A high-performance counter/timer card, the PCI-6612features 4 32-bit counter/timer channels, providing more accurate and flexible timing and counting functions than the PCI-6071E‘s 3 counter/timer channels. It is perfect for applications such as high-precision motion control systems where accurate timing is essential.

Installation and Maintenance

Pre-installation preparation

Before installing the NI PCI-6071E, ensure that your computer has an available 32-bit, 33 MHz PCI slot. Power off the computer and unplug it from the power source to avoid electrical hazards. Open the computer case carefully and locate the PCI slot. Remove the slot cover and gently insert the PCI-6071E card into the slot, making sure it is firmly seated and properly aligned. After installation, close the computer case and power on the system. Download and install the latest version of the NI-DAQmx driver software from the official NI website to ensure optimal performance and full compatibility with the card.

Maintenance recommendations

Regularly inspect the connections between the NI PCI-6071E and external devices to ensure they are secure and free from damage. Avoid excessive bending or pulling of the cables, as this can damage the connectors and disrupt data transmission. Periodically update the NI-DAQmx driver software to take advantage of the latest performance improvements, bug fixes, and new features. If the card experiences any malfunctions, such as inconsistent data acquisition or communication errors, refer to the NI product documentation for detailed troubleshooting steps. Additionally, keep the computer case clean and well-ventilated to prevent dust accumulation, which can affect the card’s performance and lifespan over time.

Product Guarantee

We stand firmly behind the quality and performance of the NI PCI-6071E multifunction data acquisition card. Each unit undergoes stringent quality control and comprehensive testing procedures to meet the highest industry standards. The PCI-6071E comes with a comprehensive warranty that covers any manufacturing defects, offering you peace of mind. Our dedicated technical support team is always on standby to assist you with any issues, whether they are related to software operation, hardware installation, or application-specific problems. We are committed to providing prompt and effective solutions to ensure that the NI PCI-6071E meets and exceeds your data acquisition and control needs throughout its service life.
