NI PCI-6230

Description

Product Overview

The NI PCI-6230 is a high-performance multifunction data acquisition (DAQ) card developed by National Instruments (NI), a leading brand in the field of measurement and automation. As a key component in the NI family of PCI – based DAQ devices, the PCI-6230 is designed to provide reliable and accurate data acquisition capabilities for a wide range of applications. This card is a versatile solution that combines analog input, analog output, digital I/O, and counter/timer functions all in one, making it an ideal choice for engineers and researchers who need to interface with real – world signals and control systems.

The NI PCI-6230 is built on the PCI bus standard, allowing it to be easily integrated into desktop computers. It serves as a bridge between physical sensors and actuators and the computer – based control and analysis software. In industrial testing, it can be used to monitor and record various physical parameters such as temperature, pressure, and vibration. In research laboratories, it enables precise data collection for experiments, helping scientists to gain valuable insights from their data. With its advanced features and high – quality performance, the NI PCI-6230 plays a crucial role in enhancing the efficiency and accuracy of data – driven processes.

Technical Specifications

NI PCI-6230

Main Features and Advantages

High – Resolution Data Acquisition

The NI PCI-6230 offers 16 – bit analog input and output resolution, ensuring highly accurate data conversion. This high resolution allows for the precise measurement of even the smallest changes in input signals, making it suitable for applications that require detailed and accurate data, such as precision sensor calibration and high – end scientific research. Whether it’s measuring the minute electrical fluctuations in a circuit or the subtle variations in a physical parameter, the PCI-6230 can capture the data with great precision.

Fast Sampling Rates

With an analog input sampling rate of up to 250 kS/s, the NI PCI-6230 can quickly acquire data, enabling it to keep up with rapidly changing signals. In applications like high – speed vibration analysis or real – time monitoring of fast – acting processes, this fast sampling rate ensures that no data is missed, providing a complete and accurate picture of the measured phenomena.

Versatile I/O Configuration

Featuring a combination of analog input, analog output, digital I/O, and counter/timer channels, the PCI-6230 offers great flexibility in system design. Engineers can configure the card according to their specific application requirements, whether it’s controlling a simple robotic arm using digital I/O or performing complex data acquisition tasks with multiple analog channels. This versatility reduces the need for multiple separate cards, simplifying the overall system setup and reducing costs.

Compatibility and Ease of Use

The NI PCI-6230 is fully compatible with the NI – DAQmx driver software, which provides an intuitive programming interface for a variety of programming languages including LabVIEW, C, C++, and Python. This makes it easy for developers with different programming backgrounds to quickly get started with the card and develop customized data acquisition and control applications.

Application Field

The NI PCI-6230 has a wide range of applications across different industries. In the automotive industry, it can be used in vehicle testing facilities to measure engine performance parameters such as temperature, pressure, and rotational speed. By accurately capturing these data, engineers can optimize engine design and improve fuel efficiency.

In the aerospace sector, the PCI-6230 is employed for testing aircraft components. It can monitor the structural integrity of parts by measuring strain and vibration, helping to ensure the safety and reliability of aircraft. In research and development laboratories, this data acquisition card is used for a variety of experiments, from material testing to studying biological signals. Scientists can use it to collect and analyze data, which is essential for advancing knowledge in their respective fields.

Moreover, in industrial automation, the NI PCI-6230 can be integrated into control systems to monitor and control production processes. It can adjust the operation of machines based on real – time data, improving production efficiency and product quality.

NI PCI-6230

Related Products

• NI PCI – 6251: This is another multifunction DAQ card from NI. It offers higher analog input sampling rates (up to 1.25 MS/s) and more analog input channels (32 single – ended / 16 differential) compared to the PCI-6230. It is suitable for applications that require extremely high – speed data acquisition and more channels.
• NI PCI – 6733: A specialized analog output card, it focuses on providing high – performance analog output capabilities. It has 32 analog output channels with 16 – bit resolution, making it ideal for applications where precise analog signal generation is crucial, such as in signal simulation systems.
• NI PCI – 6534: This digital I/O card offers a high – density digital I/O solution with 48 TTL – level digital I/O lines. It is designed for applications that mainly involve digital signal processing and control, and can be used in conjunction with the PCI-6230for more comprehensive digital control tasks.
• NI PCI – 6612: A high – performance counter/timer card, it provides 4 32 – bit counter/timer channels. It can be used to enhance the counter/timer functionality in systems where more accurate timing and counting operations are required, complementing the PCI-6230in complex measurement and control setups.
• NI PCI – 6115: A multifunction DAQ card with a balance of features, it has 16 analog input channels, 2 analog output channels, and 24 digital I/O lines. It offers a more budget – friendly option for applications that do not require the high – end features of the PCI-6230but still need reliable data acquisition capabilities.

Installation and Maintenance

Pre – installation preparation

Before installing the NI PCI-6230, ensure that your computer has an available 32 – bit, 33 MHz PCI slot. Power off the computer and unplug it from the power source to avoid any electrical hazards. Open the computer case carefully and locate the PCI slot. Remove the slot cover and gently insert the PCI-6230 card into the slot, making sure it is firmly seated. After installation, close the computer case and power on the system. Install the latest version of the NI – DAQmx driver software from the official NI website to ensure proper functionality.

Maintenance recommendations

Regularly check the connections between the NI PCI-6230 and external devices to ensure they are secure. Avoid bending or pulling on the cables excessively, as this can damage the connectors. Periodically update the NI – DAQmx driver software to benefit from the latest performance improvements and bug fixes. If the card shows any signs of malfunction, such as inconsistent data acquisition or failure to communicate, refer to the NI product documentation for troubleshooting steps. Clean the computer case and the card’s surface periodically to prevent dust accumulation, which can affect the card’s performance over time.

Product Guarantee

We stand behind the quality and performance of the NI PCI-6230 multifunction data acquisition card. Each unit undergoes rigorous testing to ensure it meets the highest industry standards. The PCI-6230 comes with a comprehensive warranty that covers any manufacturing defects. In addition, our dedicated technical support team is always available to assist you with any questions or issues you may encounter. Whether it’s software – related problems or hardware – troubleshooting, we are committed to providing prompt and effective solutions. We are confident that the NI PCI-6230 will meet your data acquisition needs and offer reliable performance throughout its lifespan.
