NI SCXI-1349

Description

Product Overview

The NI SCXI-1349 is a specialized cable adapter from National Instruments (NI), designed to bridge the connection between E-Series data acquisition (DAQ) devices and SCXI (Signal Conditioning eXtensions for Industry) modules. As part of NI’s SCXI ecosystem, this adapter plays a critical role in signal conditioning setups, enabling seamless integration between DAQ hardware and signal conditioning systems. The SCXI-1349 features a 68-pin male connector on the front panel, a 50-pin male breakout connector on the PCB, and a 50-pin rack-mount female connector on the rear, facilitating versatile wiring configurations. Engineered for industrial and laboratory environments, the adapter ensures reliable signal transmission while supporting high-voltage protection and noise immunity. It serves as an essential component for users seeking to expand measurement capabilities by integrating SCXI modules with DAQ devices, making it ideal for applications requiring precise signal conditioning and data acquisition.

Technical Specifications

NI SCXI-1349

Main Features and Advantages

Versatile Connectivity: The NI SCXI-1349 eliminates compatibility barriers by connecting 68-pin E-Series DAQ devices to SCXI modules. Its triple-connector design supports flexible wiring setups, allowing users to route signals between DAQ cards, signal conditioning modules, and external equipment with ease.
Reliable Signal Transmission: Engineered with high-voltage protection (up to 60 Vdc), the adapter safeguards both hardware and operators from electrical hazards. Its shielded construction minimizes electromagnetic interference (EMI), ensuring clean signal integrity in noisy environments.
Easy Integration with SCXI Ecosystem: As a dedicated interface for SCXI systems, the SCXI-1349 simplifies integration with NI’s signal conditioning modules, such as amplifiers, filters, and bridges. This enables users to expand measurement capabilities for applications like strain gauging, thermocouple monitoring, or high-precision voltage sensing.
Robust Industrial Design: Built to withstand industrial conditions, the adapter features durable connectors and a rugged casing. Its wide temperature range (0°C to 50°C) and non-condensing humidity tolerance make it suitable for both laboratory setups and harsh factory floors.
Cost-Effective System Expansion: By reusing existing E-Series DAQ hardware, the SCXI-1349 allows users to upgrade systems with signal conditioning capabilities without replacing core components. This makes it a cost-efficient solution for scaling measurement setups.

Application Field

The NI SCXI-1349 is widely used in industrial automation and research laboratories where precise signal conditioning is essential. In manufacturing, it supports quality control by enabling DAQ devices to interface with SCXI modules for monitoring machine vibrations, temperature fluctuations, or pressure changes in production lines. For academic research, the adapter facilitates complex experiments in materials science, where it connects strain gauges or load cells to DAQ systems via SCXI signal conditioners, allowing students and researchers to collect high-fidelity data.

In the energy sector, the SCXI-1349 plays a role in renewable energy monitoring, such as connecting solar panel voltage sensors or wind turbine vibration sensors to DAQ devices through SCXI modules. It is also utilized in automotive testing for engine performance analysis, where it bridges DAQ systems with SCXI-based charge amplifiers for piezoelectric sensor data. Additionally, the adapter supports biomedical research by enabling DAQ devices to interface with SCXI modules for amplifying and filtering physiological signals like ECG or EMG readings.

NI SCXI-1349

Related Products

SCXI-1000: A modular signal conditioning chassis compatible with the SCXI-1349, providing power and mechanical support for SCXI modules.
USB-6366: An E-Series DAQ device with 68-pin connectivity, ideal for pairing with the SCXI-1349 in portable data acquisition setups.
SCXI-1125: A bridge amplifier module that works with the SCXI-1349 to condition signals from strain gauges, load cells, or resistive sensors.
SHC68-68-EP: A shielded cable compatible with the SCXI-1349, offering 0.5 m or 1 m lengths for reliable signal transmission.
SCXI-1324: A terminal block adapter for the SCXI system, complementing the SCXI-1349 by providing additional connectivity options for field wiring.

Installation and Maintenance

Pre-installation preparation: Before deploying the NI SCXI-1349, ensure the host DAQ device (e.g., USB-6356) has a 68-pin connector and is compatible with E-Series standards. Mount the adapter in a rack or control panel using the rear 50-pin connector, ensuring proper grounding to minimize noise. Use shielded cables (e.g., SHC68-68-EP) to connect the SCXI-1349 to both the DAQ device and SCXI chassis, routing cables away from high-voltage sources to prevent interference.
Maintenance recommendations: Regularly inspect the SCXI-1349’s connectors for loose pins or corrosion, especially in humid environments. Clean the adapter with a dry cloth to remove dust or debris that could affect conductivity. If signal degradation occurs, verify cable integrity and replace damaged cables promptly. Periodically update NI-DAQmx drivers to ensure compatibility with the latest software, and refer to NI’s documentation for troubleshooting connectivity issues.

Product Guarantee

The NI SCXI-1349 is backed by NI’s 3-year warranty, covering manufacturing defects and ensuring long-term reliability. NI provides comprehensive technical support through online resources, including installation guides, driver updates, and community forums, to assist with integration and troubleshooting. Users can access free software updates for NI-DAQmx and related tools, ensuring the adapter remains compatible with evolving measurement systems. This guarantee underscores NI’s commitment to delivering robust, industry-standard solutions for signal conditioning and data acquisition, making the SCXI-1349 a trusted component for both temporary research setups and permanent industrial installations.
