Woodward 5439-730 Netcon Power Supply & Control Module
1. Product Description
The Woodward 5439-730 is a compact, high-reliability power supply and control module engineered for industrial automation, energy generation, and steam turbine systems. As part of Woodward’s Netcon series, this module integrates 24 VDC power delivery with advanced control capabilities, supporting real-time monitoring and Modbus RTU/CAN communication. Its robust design ensures operation in extreme temperatures (-40°C to +70°C) and harsh environments, making it ideal for mission-critical applications. The 5439-730 simplifies system integration by combining power supply and control functions, reducing component complexity and costs.
2. Product Parameters
| Parameter | Specification |
|---|---|
| Input Voltage | 24 VDC (±10%) |
| Current Consumption | 0.5 A (max) |
| Digital Inputs | 16 configurable channels |
| Analog Inputs | 8 channels (0–10 VDC or 4–20 mA) |
| Digital Outputs | 8 configurable channels |
| Relay Outputs | 4 relays (5 A at 28 VDC) |
| Communication Interfaces | RS-232, RS-485 |
| Protocols Supported | Modbus RTU, CAN |
| Operating Temperature | -40°C to +70°C (-40°F to +158°F) |
| Dimensions | 250 × 130 × 65 mm (9.84 × 5.12 × 2.56 in) |
| Weight | 1.8 kg (3.97 lbs) |
| Protection Features | Overvoltage, reverse polarity, short-circuit |
3. Advantages and Features
- Dual Functionality: Combines power supply and control in a single unit, minimizing space and wiring.
- Wide Temperature Range: Operates reliably in extreme climates, reducing downtime in oil & gas, mining, and marine sectors.
- Precision Control: Supports real-time parameter adjustment for steam turbines and industrial machinery.
- Flexible Communication: Seamless integration with Modbus RTU and CAN networks.
- Safety Features: Built-in protections against voltage spikes and short circuits.
4. Application Areas and Case Studies
- Energy & Power Generation: Optimizes steam turbine speed and grid synchronization.
- Industrial Automation: Controls pumps, compressors, and robotic systems in manufacturing.
- Marine/Offshore: Manages propulsion systems in harsh marine environments.
Case Study:
A European power plant improved steam turbine efficiency by 15% using the 5439-730 to synchronize speed control with grid demands, reducing maintenance costs by 20%.
A European power plant improved steam turbine efficiency by 15% using the 5439-730 to synchronize speed control with grid demands, reducing maintenance costs by 20%.
5. Competitor Comparison
- Lower Current Draw: 0.5 A vs. 0.7–1.0 A in comparable modules.
- Extended Temperature Range: Supports -40°C to +70°C, exceeding standard -20°C to +60°C options.
- Integrated Design: Combines power supply and control, simplifying system setup.
6. Selection Recommendations
- Power Needs: Ideal for 24 VDC systems with moderate current requirements.
- Environment: Use IP-rated enclosures for corrosive or dusty environments.
- Scalability: Pair with Woodward’s MICRONET modules for modular control expansion.
7. Precautions
- Voltage Compliance: Ensure input voltage matches 24 VDC ±10%.
- Ventilation: Maintain adequate airflow in high-temperature settings.
- Communication Setup: Validate protocol compatibility with existing systems.
- Relay Maintenance: Replace relays every 10 million operations for reliability.
