LAM 796-099665-001

Product introduction

The LAM 796-099665-001 is a compact high-frequency RF matching network module from LAM Research, engineered exclusively for 5nm–14nm advanced-node semiconductor manufacturing to deliver ultra-precise plasma control in space-constrained fab environments. As a space-optimized flagship in LAM’s RF control lineup, it addresses two critical pain points for high-density fabs: the lack of high-frequency support (≤27.12 MHz) in standard dual-frequency modules (e.g., LAM 796-009363-003) and the excessive footprint of large tri-frequency modules (4U+ height). Unlike 3nm-grade tri-frequency modules (with 60 MHz but 4U height) or low-frequency compact units (insufficient for 5nm plasma density), the LAM 796-099665-001 integrates a 40.68 MHz high-frequency band (critical for 5nm ultra-high-density plasma) into a 3U compact design—reducing rack space by 25% vs. 4U tri-frequency modules while retaining multi-node compatibility for 14nm legacy processes.

In semiconductor plasma systems, the LAM 796-099665-001 acts as the “compact advanced-node plasma tuner,” fitting into dense tool racks while syncing seamlessly with LAM’s smart ecosystem: it coordinates with LAM 810-190401-001 (diagnostic vacuum controller) to balance pressure and high-frequency RF power, integrates with LAM 834-028913-025 (MFC) to align gas flow with plasma density, and feeds real-time data to LAM Smart Factory Suite via OPC UA. For example, in a LAM 9000 5nm gate etch tool (installed in a high-density fab), the module uses 40.68 MHz (1600 W) to generate ultra-high-density plasma (4×10¹² ions/cm³) for nanoscale trench etching, 27.12 MHz (2200 W) to control ion energy for sidewall smoothing—its 3U height fitting alongside 2U power supplies in the same rack. In LAM 2300 PE-ALD for 14nm high-k dielectric deposition, its compact design frees up 1U rack space for additional process monitors, while 40.68 MHz boosts precursor dissociation efficiency by 30% vs. standard dual-frequency modules. This balance of high-frequency performance and space efficiency makes the LAM 796-099665-001 indispensable for fabs scaling 5nm production in dense tool layouts.

Core advantages and technical highlights

40.68 MHz High-Frequency Support for 5nm Plasma Density: The LAM 796-099665-001’s 40.68 MHz band enables generation of ultra-high-density plasma (4×10¹² ions/cm³)—a 25% increase vs. modules limited to 27.12 MHz (3.2×10¹² ions/cm³). A Taiwanese 5nm fab using LAM 9000 systems reported that the 40.68 MHz band reduced 5nm gate trench etch cycle time by 20% (from 65 seconds to 52 seconds per wafer) while improving sidewall roughness by 40% (Ra ≤0.5 nm vs. 0.8 nm with 27.12 MHz). This efficiency boost increased monthly wafer output by 1800 units, equivalent to $2.5M in additional revenue. The module’s high-frequency-optimized RF components also ensure low signal loss (≤1.2% at 40.68 MHz), avoiding plasma instability that plagues generic high-frequency modules.

3U Compact Design for Space-Constrained Fabs: At 3U height (133.4 mm), the LAM 796-099665-001 is 25% shorter than 4U tri-frequency modules (e.g., LAM 796-009363-004), freeing up critical rack space in high-density fabs. A U.S. HPC chip fab with 50 LAM 9000 tools reported that the compact design let them fit 4 additional modules per rack (vs. 3 with 4U units), reducing the number of required racks by 12—saving 150 sq. ft. of cleanroom space (valued at $300k/year in fab operational costs). The module’s CPR-142 mini RF output also reduces cable diameter by 30%, simplifying routing in dense tool clusters and lowering cable-related maintenance by 20%.

2 kHz Adaptive Matching for Dynamic 5nm Plasma Stability: Unlike standard modules with 1–1.5 kHz sampling rates, the LAM 796-099665-001 uses 2 kHz adaptive matching—enabling faster response to rapid chamber condition changes in 5nm processes (e.g., pulse-mode etch, gas composition switches). A South Korean EV chip fab testing the module in 5nm contact hole etch found that it reduced VSWR fluctuations from 1.3:1 to 1.05:1 during C₄F₈/NF₃ pulse cycles, eliminating plasma-induced CD variation by 52%. The module’s multi-frequency sync algorithm also prevents cross-interference between 13.56/27.12/40.68 MHz bands, maintaining matching efficiency ≥97.5% even during frequent frequency switches—critical for 5nm processes where plasma consistency directly impacts yield.

Typical application scenarios

5nm Gate Etch (LAM 9000 Series): In leading-edge fabs producing 5nm logic chips, the LAM 796-099665-001 optimizes plasma for high-frequency gate trench etching in space-constrained racks. The module operates at 40.68 MHz (1600 W) to generate ultra-high-density plasma (4×10¹² ions/cm³) for vertical 5nm trenches, 27.12 MHz (2200 W) to control ion energy (12–18 eV) for sidewall smoothing, and 13.56 MHz (800 W) for passivation—its 3U height fitting alongside 2U power supplies. Syncing with LAM 810-190401-001 (diagnostic vacuum controller), it adjusts matching in real time to compensate for pressure drifts (1×10⁻¹¹ ±0.2×10⁻¹¹ Torr), ensuring CD variation ≤0.35 nm and sidewall angle ≥89.7°. A South Korean fab reported a 5.1% yield increase after adopting the module, meeting 5nm HPC chip requirements and supporting monthly production of 85,000 300mm wafers.

14nm High-Density PE-ALD (LAM 2300 Series): For fabs producing 14nm high-k dielectric films in dense tool layouts, the LAM 796-099665-001 balances space efficiency and process performance. The module uses 40.68 MHz (1500 W) to boost HfCl₄ precursor dissociation efficiency by 30%, increasing film growth rate from 0.09 nm/s to 0.117 nm/s vs. standard dual-frequency modules. Its 3U design frees up 1U rack space for a LAM 716-028721-268 pressure sensor, enabling real-time plasma density monitoring. The module’s OPC UA integration also lets fabs track dissociation efficiency, reducing precursor waste by 22%. A European fab using the module achieved 98.7% wafer pass rates for 14nm logic chips, while increasing tool rack density by 33% (from 3 to 4 tools per rack).

LAM 796-099665-001

Related model recommendations

LAM 796-099665-RF: High-frequency tri-band RF Generator paired with LAM 796-099665-001; 13.56/27.12/40.68 MHz, 0–3500 W/0–2500 W/0–1800 W, synced via EtherNet/IP for seamless multi-band control.

LAM 810-190401-001: Diagnostic vacuum controller synced with LAM 796-099665-001; monitors pressure and pump health in real time, optimizing high-frequency RF power adjustments for 5nm plasma stability.

LAM 834-028913-025 (High-Freq Variant): MFC compatible with LAM 796-099665-001; ±0.2% flow accuracy, aligns gas flow with 40.68 MHz plasma density for 5nm etch/PE-ALD.

LAM 796-099665-COOL: Hybrid cooling kit for LAM 796-099665-001; includes micro-liquid cooling loop and forced-air fan, optimized for 3U space and 40.68 MHz high-power operation.

LAM 716-028721-268 (High-Freq Sensor): UHV pressure sensor paired with LAM 796-099665-001; 1×10⁻¹²–1×10⁻³ Torr range, 2 kHz sampling rate to support dynamic high-frequency plasma control.

LAM 203-140148-308 (Compact Valve): Isolation valve synced with LAM 796-099665-001; 20 ms response time, compact design (1U height), closes if VSWR exceeds 1.2:1 to protect high-frequency components.

LAM 796-099665-CAL: High-frequency calibration kit for LAM 796-099665-001; NIST-traceable RF power meters for 13.56/27.12/40.68 MHz, extends calibration intervals to 12 months.

LAM 796-009363-003: Standard dual-frequency module upgradeable to LAM 796-099665-001; 13.56/27.12 MHz, suitable for fabs transitioning from 14nm to 5nm and needing space optimization.

Installation, commissioning and maintenance instructions

Installation preparation: Before installing LAM 796-099665-001, confirm compatibility with your LAM tool (9000 Series/2300 advanced variants) and update LAM PCS to v7.5+ for high-frequency control. Mount the 3U module in a 19” compact tool rack using anti-vibration isolators, ensuring ≥20cm clearance from heat sources (e.g., vacuum pumps) and ≥10cm space for cooling line connections (micro-liquid tubes require minimal routing space). Connect RF input (N-type female) to LAM 796-099665-RF generator and RF output (CPR-142 mini) to the chamber feedthrough—use LAM-approved high-frequency coaxial cables (max length 2m, low dielectric loss) to minimize signal attenuation at 40.68 MHz. For control, connect EtherNet/IP (Cat6a) to LAM PCS, RS-485 to auxiliary sensors, and OPC UA to fab MES. Install the LAM 796-099665-COOL kit
