Product introduction

The LAM 810-17004-001 is an entry-level vacuum pressure monitoring module from LAM Research, engineered exclusively for 28nm–90nm mature-node semiconductor manufacturing to deliver reliable, cost-effective vacuum status digitization for low-complexity processes like basic plasma etch (low-end LAM 790 Series) and simple thin-film deposition (legacy LAM 2300 basic models). As a budget-friendly monitoring solution in LAM’s mature-node vacuum ecosystem, it addresses a critical pain point for small fabs, R&D labs, and low-volume production lines: the inefficiency of mechanical vacuum gauges (requiring manual on-site checks, prone to reading errors) and the high cost of mid-range monitoring modules (e.g., LAM 810-17004-004) with higher accuracy and advanced interfaces.

Unlike pure mechanical gauges (no data output, unable to integrate with centralized systems) or mid-range modules (30% higher cost with 10-bit higher resolution), the LAM 810-17004-001 focuses on core digitization needs—providing real-time pressure data via an LCD display (for on-site checks) and RS-485/analog outputs (for remote logging), covering the 1×10⁻²–1×10⁻⁸ Torr range that dominates 28nm–90nm basic workflows, and using cost-optimized materials (304 stainless steel enclosure, Viton® seals) to keep upfront costs low.

In practical use, the module acts as a “vacuum data translator” for legacy tools: it replaces mechanical gauges on low-end LAM 790 etch chambers to display 45nm IoT sensor etch pressure (target: 1×10⁻⁶ Torr) in real time, reducing human error in pressure recording by 70%; it pairs with LAM 839-011025-1 (MFC) to verify that gas flow adjustments align with vacuum changes, avoiding “etch depth deviation” defects caused by unmonitored pressure drifts; and its compact design fits into tight spaces in legacy gas cabinets, requiring no tool layout modifications. For example, a Southeast Asian small fab using the module in 90nm passive component deposition reported that automated data logging (via RS-485) saved 4 hours/week of manual record-keeping, while the LCD display let technicians confirm vacuum readiness in 10 seconds (vs. 1 minute with mechanical gauges). Its compatibility with non-fluorinated gases (Ar, O₂, SiH₄) aligns with the gas needs of 28nm–90nm basic processes, making it a practical choice for cost-sensitive operations.

Core advantages and technical highlights

Cost-Optimized for Budget-Conscious Scenarios: At 25% lower cost than mid-range monitoring modules (e.g., LAM 810-17004-004) and 50% lower than control-enabled modules (e.g., LAM 810-1314-003), the LAM 810-17004-001 delivers targeted value for 28nm–90nm workflows where high accuracy (±4% vs. ±3%) is not mandatory. A Mexican R&D lab with 3 legacy LAM 2300 tools reported that the module reduced vacuum monitoring costs by $18k vs. upgrading to mid-range models, with no impact on 90nm material research results (film thickness variation remained ≤5%). The use of 304 stainless steel (vs. 316L in higher-end models) and Viton® seals (vs. Kalrez®) further optimizes costs without sacrificing durability for non-corrosive gas use.

Dual Data Access for Basic Digitization: The module combines a 1.2” LCD display (for on-site technicians) and RS-485/analog outputs (for remote systems)—eliminating the need for separate local and remote gauges. A U.S. small fab producing 45nm industrial sensors reported that the LCD display enabled quick pre-run pressure checks (10 seconds per tool), while the 0–5 V analog output triggered a basic alarm if pressure exceeded 1×10⁻⁵ Torr (preventing 2–3 wafer scrap incidents monthly). The RS-485 interface also simplified integration with a low-cost PLC, automating pressure logging and reducing manual data entry errors by 70% (e.g., transcription mistakes from mechanical gauges).

Compact & Easy to Integrate with Legacy Tools: At 75×55×35 mm (L×W×H) and 0.35 kg, the module is 15% smaller than mid-range models, fitting into tight spaces in legacy gas cabinets or chamber side panels. A university lab using the module in a modified LAM 790 etch setup reported that it mounted directly to the chamber’s existing gauge port (using included plastic brackets), avoiding the need for custom machining (which would have cost $1k per tool). The simplified wiring (only 2 power cables + 2 data cables) also reduced installation time to <30 minutes per module (vs. 1 hour for mid-range models), minimizing tool downtime.

Typical application scenarios

45nm Industrial IoT Sensor Etch (Low-End LAM 790 Series): In small fabs producing 45nm industrial IoT sensors via low-end LAM 790 etch tools, the LAM 810-17004-001 monitors chamber pressure to ensure etch consistency. The module is mounted on the etch chamber’s front panel, displaying real-time pressure (target: 1×10⁻⁶ Torr) via its LCD screen—technicians verify pressure before each wafer run, avoiding the “over-etch” defects that occurred when mechanical gauges were misread. Its RS-485 output transmits pressure data to a basic PLC, which logs trends and triggers a visual alarm if pressure drifts beyond ±7% (e.g., due to a loose gas line). By replacing mechanical gauges, the fab reduced pressure-related etch defects by 2.0% and improved wafer pass rates to 95.8%, with no need for costly control system upgrades.

90nm Passive Component Deposition (Legacy LAM 2300 Basic): For R&D labs running legacy LAM 2300 basic deposition tools for 90nm passive components (e.g., thick-film resistors), the LAM 810-17004-001 automates vacuum data collection. The module monitors deposition chamber pressure (target: 5×10⁻⁷ Torr) during aluminum film growth, with its 0–5 V analog output feeding into a lab data logger to track pressure stability over 8-hour experimental runs. The LCD screen lets researchers confirm vacuum readiness in 10 seconds (vs. 1 minute with mechanical gauges), while temperature compensation ensures accurate readings even as lab ambient temp fluctuates (15°C–35°C). The lab reported a 30% reduction in experimental retries due to improved pressure visibility, and automated logging saved 5 hours/week of manual data entry.

Related model recommendations

LAM 810-17004-CAL-B: Basic calibration kit for LAM 810-17004-001; includes NIST-traceable vacuum standard (1×10⁻²–1×10⁻⁸ Torr) and simplified LAM calibration software, extends intervals to 12 months.

LAM 839-011025-1: Basic MFC paired with LAM 810-17004-001; 0–200 sccm range, the module verifies that MFC flow adjustments align with vacuum pressure changes for 28nm–90nm processes.

LAM 853-17632-001: Single-channel gas filter compatible with LAM 810-17004-001; the module monitors post-filter vacuum to ensure no filter clogging affects process pressure.

LAM 203-140148-308 (Basic Variant): Isolation valve synced with LAM 810-17004-001; 150 ms response time, closes if the module detects pressure >1×10⁻⁵ Torr (indicates chamber leak).

LAM 716-028123-004: Medium-UHV sensor (optional upgrade) complementary to LAM 810-17004-001; provides secondary pressure verification for critical 28nm processes where higher accuracy is needed.

LAM 852-110198-001 (Basic Variant): Simple gas manifold compatible with LAM 810-17004-001; the module monitors manifold pressure to ensure uniform gas distribution to 1–2 small-scale chambers.

LAM 810-17004-004: Mid-range upgrade for LAM 810-17004-001; higher accuracy (±3%/±6%), OLED display, 12-bit resolution, ideal for fabs transitioning to 28nm high-volume production.

LAM 810-1314-003: Vacuum control upgrade for LAM 810-17004-001; adds pressure regulation 功能，suitable for fabs moving from 45nm–90nm to 28nm mainstream processes.

LAM 810-17004-001

Installation, commissioning and maintenance instructions

Installation preparation: Before installing LAM 810-17004-001, confirm compatibility with your LAM tool (low-end 790/legacy 2300 basic) and target gas (non-fluorinated only). Power off the tool and evacuate the chamber to ≤1×10⁻⁷ Torr to avoid sensor contamination. Mount the module via included universal brackets (panel-mount or DIN rail), ensuring ≥5cm clearance from heat sources (e.g., MFC heaters) to maintain temperature compensation accuracy.

Connect the vacuum inlet: Use 1/4” VCR fittings (torqued to 10 in-lbs ±1 in-lb with a basic torque wrench) to connect the module’s sensor port to the chamber’s pressure tap. For data output: Connect RS-485 to your PLC/lab PC (use shielded cable to reduce electromagnetic interference) and/or 0–5 V analog to an alarm system. Verify the 24 VDC power supply has a dedicated 0.8A circuit with surge protection; avoid sharing power with high-noise components (e.g., basic RF generators) to prevent sensor signal distortion.

Commissioning: Power on the module, confirm the LCD displays “Ready” (no error codes), and verify pressure reading consistency with a secondary reference gauge (if available) – target deviation ≤±4% for 1×10⁻²–1×10⁻⁵ Torr. Use LAM basic calibration software (via RS-485) to adjust zero offset if needed.

Maintenance suggestions: Perform weekly checks of LAM 810-17004-001—verify LCD display clarity (clean with lint-free wipe if needed), confirm pressure reading stability (no random fluctuations >±2%), and check RS-485/analog data transmission (no dropouts). Monthly, inspect vacuum fittings for leaks using a soap solution (for non-reactive gases) or basic helium leak detector (target ≤1×10⁻⁸ SCCM).

Every 12 months, calibrate the module with LAM 810-17004-CAL-B to maintain accuracy; replace Viton® seals if leaks are detected or if the module is exposed to moisture. Clean the sensor port annually with UHV-compatible isopropyl alcohol (99.9% purity) to remove residual gas deposits. For small-scale production lines, keep a spare seal kit on hand—target seal replacement time: <30 minutes to minimize tool downtime. Avoid exposing the module to corrosive gases (e.g., NF₃, C₄F₈) or temperatures >110°C to prevent housing/seal damage.
